Accessories included -
Antenna - Built-in
Antenna - Antenna direction type - Omni-directional
Antenna - Antenna gain level (max) - 3 dBi
Antenna - Antennas quantity - 2
Antenna - Antenna type - Internal
Antenna > Antennas quantity - 2
Antenna > Antenna type - 2xInternal
Antenna gain - 3 dBi
ARTIKEL1 - WIRELESS AC1300 WAVE2
ARTIKEL2 - PARALLEL-BAND POE ACCESS POINT
Brand - D-Link
BrandPartCode - DAP-2610
Category - Root/Electronics/Networks and communication/Access points
Category - Wireless Access Points
Category_1 - Network and Servers
Category_2 - Network - WiFi Access Points
Code - DAP-2610
Color - White
Description - DAP-2610 AP AC1300 PoE DualBand
DAP-2610 is a manageable two-band access point with connection support in the 802.11ac Wave 2 standard, designed to build WiFi networks in companies of all sizes.
Design - Certification - FCC
IC
CE
UL
Design - Internal - No
Design - LED indicators - Power, Status
Design - Placement - Ceiling, Table, Wall
Design - Product colour - White
dimension depth - 65 mm
dimension height - 270 mm
Dimensions - 170 x 170 x 28 mm
dimension weight - 695 g
dimension width - 205 mm
EAN - 790069430855
ean - 790069430855
EANCode - 0790069430855
Eans - 790069430855
EAN_code - 0790069430855
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Ethernet LAN data rates - 100,1000 Mbit/s
Features - Maximum data transfer rate - 1000 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 867 Mbit/s
Features - Networking standards - IEEE 802.3ab, IEEE 802.3u
Features > Mesh Support - No
Features > Mobile Broadband - No mobile broadband
Features > MU-MiMO - Yes
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 790069430855
GTIN - 0790069430855
GTIN - 0790069430879
GTIN - 790069430879
GTIN - 0790069430909
GTIN - 790069430909
GTIN - 0790069443763
GTIN - 790069443763
guarantee - -1
guarantee_type - external
HERSTELLER - D-LINK
HSTNUMMER - DAP-2610
I/O ports - 1 x 10/100/1000 Mbit/s PoE
Laenge - 0.27
Link - https://eu.dlink.com/uk/en/products/dap-2610-wireless-ac1300-wave-2-dualband-poe-access-point
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Free Nuclias Connect Remote Centralized Management SoftwareD-Link’s Nuclias Connect is a centralized management and analytics solution that brings convenience, control, customizability and cost-effective scaling to SMB (small-medium-sized business) networks. It enables network monitoring, management, and device configuration through a single, easy-to-use software interface.What’s more – it’s free to download and there are no licensing or support fees. Easily manage your network, anytime, anywhere.Multi-Mode Makes the Most of your Network CapabilitiesIn order to achieve optimal network performance, the DAP-2610 has several operational modes tailored to best fit the individual needs of your network. Access Point, Wireless Client, WDS (Wireless Distribution System), and WDS with Access Point modes allow for flexible, customizable deployment whatever your requirements.In a World Where Time is Money, Speed is EssentialIncrease employee productivity with access to the data they require at combined speeds of up to 1300 Mbps while ensuring the same high-level throughput for your guest networks, too with 2 x 2 MU MIMO technology’s multiple device connectivity. An added Gigabit LAN port allows for high-capacity backhaul to the wired network.Take a Load Off and Let Your AP do the Hard WorkThe DAP-2610’s Load Balancing feature spreads the work load between two or more Access Points to get optimal resource utilization, throughput and response time, while Airtime Fairness helps distribute equal amounts of air time to each connected client. Band Steering auto-connects devices such as smart phones and tablets to the higher-capacity 5 GHz band while allowing devices 2.4 GHz-ready to remain. The result is a steady, consistent connection for each user – the perfect balancing act.Expand your Network withBudget in MindNuclias Connect’s evolving software-based management capabilities allow you to invest in the DAP-2610 confident that as your business growth expands, your network will, too. Manage up to 1000 Access Points from a single central location, wherever you are, whenever you want.Industrial Design RedefinedThe DAP-2610 perfectly marries industrial grade materials with subtle, clean-line design. Its fresh white housing blends well into any indoor space, while its soft, rounded corners ensure an elegant integration wherever it’s placed.Peak Performance and Discreet Deployment with Power over Ethernet (PoE)The DAP-2610’s Power over Ethernet function allows for easy installation and a simple, clean setup. No need to run extra power lines, no added hassle when configuring your hardwiring and no more cable clutter. Perfect for advanced installations in areas where power outlets are not readily available.Make Every Second Count with Advanced Quality of Service (QoS)The DAP-2610 not only delivers reliable wireless performance with maximum wireless signal rates of up to 400 Mbps in the 2.4 GHz band and 867 Mbps in the 5 GHz band but, Wi-Fi Multimedia (WMM™) support enhances your network’s Quality of Service (QoS) by cleverly prioritizing different types of traffic. With the use of QoS, WMM ensures that applications such as, audio, video and voice, that require better throughput and more performance are placed in order of high-to-low priority for an all-round smoother, uninterrupted Wi-Fi experience.Complete Control over your Network’s AccessComplete control comes as standard with the DAP-2610. Combined with the Nuclias Connect Software, a variety of the latest in network security and management tools are at your fingertips. You can rest assured that the best of the best are hard at work keeping your network better protected and hitch free.Big Things Start SmallNetworks big or small all have to start somewhere, with devices sometimes having to take on duties that would not normally be expected of them. For the DAP-2610 that is not a problem since its stand-alone capabilities mean it can take on multiple roles effortlessly. It can be deployed within a small office or classrooms, for example, to create or expand the capacity of a wireless network.The Beating Heart of Your NetworkAt the heart of your network is the DNH-100 Wireless Controller, or ‘The Hub’. It centralizes all aspects of your Access Points’ provisioning and management, allowing them to work together as a team. Features such as self-organizing, self-optimizing and self-healing keep the network performing at its peak.
LongProductName - DAP-2610 Nuclias Connect Wireless AC1300 Wave 2 DualBand PoE Access Point
LongSummaryDescription - D-Link Nuclias Connect AC1300 Wave 2 Dual-Band Access Point. Maximum data transfer rate: 1000 Mbit/s, Maximum data transfer rate (5 GHz): 867 Mbit/s, Ethernet LAN data rates: 100,1000 Mbit/s. Security algorithms: 64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSID, WPA, WPA2. Management protocols: SNMP v1 / v2c / v3. AC input voltage: 12 V, Input current: 1 A, Power consumption (max): 12 W. Placement: Ceiling, Table, Wall, Product colour: White, LED indicators: Power, Status
Management, monitoring, configuration - - Telnet
- Secure Telnet (SSH)
- Web (HTTP)
- Secure Socket Layer (SSL)
- Traffic control
- SNMP v1/v2c/v3
- D-Link Central Wi-Fi Manager
- AP Array
Manufacturer - D-Link
Manufacturer_code - DAP-2610
Name - D-Link DAP-2610
Name - D-Link DAP-2610, Access Point
Name - D-Link | Wireless AC1300 Wave 2 DualBand PoE Access Point | DAP-2610 | 802.11ac | Mesh Support No | 400+867 Mbit/s | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 1 | No mobile broadband | MU-MiMO Yes | PoE in | Antenna type 2xInternal
name - DAP-2610 AP AC1300 PoE DualBand
Network architecture - GigabitEthernet
Number of antennas - 2
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 65 °C
Other features - MTFB 30,000 hours
Other features > Ethernet LAN (RJ-45) ports - 1
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 30.00 mm
Package features > Gross height (mm) - 180.00 mm
Package features > Gross width (mm) - 180.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 1778 pc(s)
Package features > Paper/Pasteboard - 190.00 g
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.20 kg
Package features > TI weight (kg) - 0 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging data - Package depth - 269 mm
Packaging data - Package height - 64 mm
Packaging data - Package weight - 134.8 g
Packaging data - Package width - 204 mm
Performance > Ethernet LAN data rates - 10/100/1000 Mbit/s
Performance > Wi-Fi data rate (max) - 400+867 Mbit/s
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > POE - PoE in
Power - AC input voltage - 12 V
Power - Input current - 1 A
Power - Power consumption (max) - 12 W
Power - Power over Ethernet (PoE) - Yes
Power supply - - POE
- External 12 V/1 A power supply (not included)
producer - D-Link
Producer - D-link
ProducerCode - DAP-2610
Producer product family - Wireless AC1300 Wave 2 DualBand PoE Access Point
Producer product name - DAP-2610
ProductName - D-Link Nuclias Connect AC1300 Wave 2 Dual-Band Access Point
Protocols - Management protocols - SNMP v1 / v2c / v3
Security - - WPA-Personal
- WPA-Enterprise
- WPA2-Personal
- WPA2-Enterprise
- WEP 64/128-bit encryption
- SSID broadcast disable
- MAC address access control
- Network Access Protection (NAP)
- Internal RADIUS server
Security - Security algorithms - 64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSID, WPA, WPA2
ShortDescription -
ShortSummaryDescription - D-Link Nuclias Connect AC1300 Wave 2 Dual-Band Access Point, 1000 Mbit/s, 867 Mbit/s, 100,1000 Mbit/s, IEEE 802.3ab, IEEE 802.3u, 64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSID, WPA, WPA2, SNMP v1 / v2c / v3
Software -
Special functions -
Standards - 802.3ab
Standards - 802.3u
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 5
Stck_Pal - 0
Storno - N
System Requirements -
Technical details - Master (outer) cases per pallet (air) - 96 pc(s)
Technical details - Master (outer) cases per pallet (sea) - 96 pc(s)
Technical details - Pallet gross length - 110.1 cm
Technical details - Pallet gross weight (air) - 400.2 kg
Technical details - Pallet gross weight (sea) - 400.2 kg
Technical details - Pallet gross width - 120 cm
Technical details - Pallet height (air) - 2.05 m
Technical details - Pallet height (sea) - 2.05 m
Technical details - Products per pallet (air) - 480 pc(s)
Technical details - Products per pallet (sea) - 480 pc(s)
Technical details - Products per shipping (inner) case - 5 pc(s)
Technical details - Shipping (inner) case gross weight - 3.95 kg
Technical details - Shipping (inner) case height - 22.4 cm
Technical details - Shipping (inner) case length - 35.6 cm
Technical details - Shipping (inner) case net weight - 2 kg
Technical details - Shipping (inner) case width - 28.4 cm
Technical details > Gross weight - 0.51 kg
Technical details > Net weight - 0.31 kg
Technical details > Producer - D-Link
Title - D-Link Nuclias Connect AC1300 Wave 2 Dual-Band Access Point
Unboxing -
URL - https://eu.dlink.com/uk/en/products/dap-2610-wireless-ac1300-wave-2-dualband-poe-access-point
vendpn - DAP-2610
Warranty - 60
Warranty - 60 month(s)
WarrantyInfo - Limited Lifetime
Weight - 0,68
Weight - 370.6 g
Weight & dimensions - Depth - 170 mm
Weight & dimensions - Height - 28 mm
Weight & dimensions - Weight - 314 g
Weight & dimensions - Width - 170 mm
Wireless LAN features > Wi-Fi band - 802.11ac
Wireless LAN features > Wi-Fi standards - 802.11a/b/g/n/ac
