ID: 158969
Tuotekoodi: NF-F12-PWM
Voidaan tilata 66 yksiköt Saatavuus: 14 päivää tilauksen hyväksymisestä
Takuu: 3 vuotta
Noctua NF-F12 PWM
Kuva voi poiketa todellisesta tuotteesta, ja tuotteessa voi olla lisävarusteita ja osia, joita ei toimiteta varsinaisen tuotteen mukana.
Tärkeimmät tuoteparametrit Kaikki parametrit
- Tuottaja: Noctua
- Kierrokset (MIN), rpm: 300
- Koko, mm: 120
- LED-taustavalon väri: Ei ole
- Lähtöliitäntä: 4-pin (PWM)
- RPM (MAX), rpm: 1500
- Yksiköt pakkauksessa: 1
- Äänitaso (MAX), dB(A): 22.4
Kaikki parametrit
Tuottaja
: Noctua
Valaistustyyppi
: Bez apgaismojuma
Perustiedot
Koko, mm
: 120
LED-taustavalon väri
: Ei ole
Lähtöliitäntä
: 4-pin (PWM)
RPM (MAX), rpm
: 1500
Yksiköt pakkauksessa
: 1
Äänitaso (MAX), dB(A)
: 22.4
Yksityiskohtaisempi erittely
category - Air Cooling Fans
Category - Root/Electronics/PC parts/Cooling/Casing fans
Category_1 - Computer Cases and Cooling
Category_2 - Fans
code - NF-F12-PWM
Design - Product colour - Beige
Design - Product colour - Bronze
dimensionalWeight - 220
ean - 4716123314660
Eans - 4716123314660
EAN_code - 4716123314660
Logistics data - Harmonized System (HS) code - 84733080
Manufacturer - Noctua
Manufacturer_code - NF-F12 PWM
Name - Noctua NF-F12 PWM
Name - Noctua NF-F12 PWM - 120mm
name - Noctua NF-F12-PWM Lüfter - 120mm
Performance - Airflow - 93.4 m³/h
Performance - Fan diameter - 12 cm
Performance - Maximum air pressure - 2.61 mmH2O
Performance - Mean time between failures (MTBF) - 150000 h
Performance - Minimum air pressure - 1.83 mmH2O
Performance - Noise level (high speed) - 22.4 dB
Performance - Noise level (low speed) - 18.6 dB
Performance - Quantity per pack - 1 pc(s)
Performance - Rotational speed (max) - 1500 RPM
Performance - Rotational speed (min) - 300 RPM
Performance - Suitable location - Computer case
Performance - Type - Fan
Power - Hub current - 0.05 A
Power - Power consumption (typical) - 0.6 W
Power - Rated voltage - 12 V
Producer - Noctua
ProducerCode - NF-F12
producerCode - NF-F12 PWM
productName - Noctua NOC-NF-F12-PWM Computer case Fan 12 cm Beige, Brown 1 pc(s)
productSize - Normal
ShortDescription - 120mm 300-1200(1500) RPM
sizeX - 150
sizeY - 35
sizeZ - 210
Technical_details - Attachment screwed Power Connection PWM fan connector Fan Bearing SSO Power Input 0 - 0.6 watt(s) Voltage Range 0 - 12 V Number of Revolutions 300 - 1500 rpm Volume 0 - 22.4 dB(A) Volumetric Flow 0 - 93.4 m3/h, 0 - 55 cfm Dimensions Fans Fan 1 120 x 120 x 25 mm Features with Temperature-Sensor Yes RoHS Compliant Yes
warrantyLength - 72
warrantyType - F
Weight - 0,32
weight - 298
Weight & dimensions - Depth - 25 mm
Weight & dimensions - Height - 120 mm
Weight & dimensions - Width - 120 mm
Category - Root/Electronics/PC parts/Cooling/Casing fans
Category_1 - Computer Cases and Cooling
Category_2 - Fans
code - NF-F12-PWM
Design - Product colour - Beige
Design - Product colour - Bronze
dimensionalWeight - 220
ean - 4716123314660
Eans - 4716123314660
EAN_code - 4716123314660
Logistics data - Harmonized System (HS) code - 84733080
Manufacturer - Noctua
Manufacturer_code - NF-F12 PWM
Name - Noctua NF-F12 PWM
Name - Noctua NF-F12 PWM - 120mm
name - Noctua NF-F12-PWM Lüfter - 120mm
Performance - Airflow - 93.4 m³/h
Performance - Fan diameter - 12 cm
Performance - Maximum air pressure - 2.61 mmH2O
Performance - Mean time between failures (MTBF) - 150000 h
Performance - Minimum air pressure - 1.83 mmH2O
Performance - Noise level (high speed) - 22.4 dB
Performance - Noise level (low speed) - 18.6 dB
Performance - Quantity per pack - 1 pc(s)
Performance - Rotational speed (max) - 1500 RPM
Performance - Rotational speed (min) - 300 RPM
Performance - Suitable location - Computer case
Performance - Type - Fan
Power - Hub current - 0.05 A
Power - Power consumption (typical) - 0.6 W
Power - Rated voltage - 12 V
Producer - Noctua
ProducerCode - NF-F12
producerCode - NF-F12 PWM
productName - Noctua NOC-NF-F12-PWM Computer case Fan 12 cm Beige, Brown 1 pc(s)
productSize - Normal
ShortDescription - 120mm 300-1200(1500) RPM
sizeX - 150
sizeY - 35
sizeZ - 210
Technical_details - Attachment screwed Power Connection PWM fan connector Fan Bearing SSO Power Input 0 - 0.6 watt(s) Voltage Range 0 - 12 V Number of Revolutions 300 - 1500 rpm Volume 0 - 22.4 dB(A) Volumetric Flow 0 - 93.4 m3/h, 0 - 55 cfm Dimensions Fans Fan 1 120 x 120 x 25 mm Features with Temperature-Sensor Yes RoHS Compliant Yes
warrantyLength - 72
warrantyType - F
Weight - 0,32
weight - 298
Weight & dimensions - Depth - 25 mm
Weight & dimensions - Height - 120 mm
Weight & dimensions - Width - 120 mm
