Accessories included - 2 x Battery Configuration instructions HDMI cable Power cable Monitor Remote
ARTIKEL1 - M861 86IN LFD UHD
ARTIKEL2 - 500CD/M2 DIRECT LED BACKLIGHT
Aspect ratio - 16:9
Audio - Built-in speaker(s) - Yes
Audio - Number of built-in speakers - 2
Audio - RMS rated power - 10 W
Auto Pivot - Yes
Bluetooth - No
Brand - NEC
BrandPartCode - 60005067
Breite - 1.23
Brightness - 500 cd/m²
Category - Signage Displays
Color - Black
Curved - 0 R
Depth - 83.2 mm
Description - Intuitive delivery of professional content First impressions are key, so presenting your business in the best possible way allows you to create momentum for your brand. M series monitors are equipped with a thin panel with a modern design, capable of 24/7 operation, and with a high degree of haze, which helps reduce reflections in high ambient light levels. This allows you to professionally communicate your message while maintaining an attractive price of the system. The optional NEC MediaPlayer or the even more powerful Intel Smart Display Module (Intel SDM) enable intuitive content creation and real-time media playback for exceptional viewing experiences. The M Series provides rich, upgradeable features for advertising, infotainment and meeting rooms. At the same time, the appearance of the devices seamlessly fits into the aesthetics of any brand. Flawless readability - no reflections from windows and other light sources eliminates problems with the visibility of information and advertising content and presentations in conference rooms Enriched image parameters - advanced settings of all important visual parameters allow full adjustment of brightness, color, gamma value and uniformity via the SpectravVew Engine system. Ready to operate 24/7 in mission-critical applications - carefully selected industrial-grade components and carefully designed for demanding operating environments, combined with a lasting, highly positive customer experience. Future-proof technology connectivity - The device is equipped with multiple industry-standard digital and analog signal inputs for flexible integration with AV infrastructures. Secure Remote Management - Devices can be remotely controlled securely using NEC NaviSet Administrator 2 software; proactively managing maintenance requirements saves time and resources
Design - Bezel width (bottom) - 1.48 cm
Design - Bezel width (side) - 1.43 cm
Design - Bezel width (top) - 1.43 cm
Design - Orientation - Horizontal/Vertical
Design - Panel mounting interface - 600 x 400 mm
Design - Product colour - Black
Design - Product design - Digital signage flat panel
Design - VESA mounting - Yes
Designation - CE+WEEE
dimension depth - 2100 mm
dimension height - 1200 mm
dimension weight - 62000 g
dimension width - 230 mm
Display - Contrast ratio (typical) - 8000:1
Display - Display brightness - 500 cd/m²
Display - Display diagonal - 2.18 m (86")
Display - Display diagonal (metric) - 217.4 cm
Display - Display number of colours - 1.073 billion colours
Display - Display resolution - 3840 x 2160 pixels
Display - Display technology - LCD
Display - Haze rate - 28%
Display - HD type - 4K Ultra HD
Display - Horizontal scan range - 15 - 135 kHz
Display - LED backlight - Yes
Display - LED backlighting type - Direct-LED
Display - Native aspect ratio - 16:9
Display - Panel type - IPS
Display - Response time - 8 ms
Display - Vertical scan range - 23 - 76 Hz
Display surface - Matt
ean - 5028695125247
EANCode - 5028695125247
Energy class - G
Energy label - Pobierz
Frequency, horizontal max. - 135 kHz
Frequency, horizontal min. - 15 kHz
Frequency, vertical max. - 76 Hz
Frequency, vertical min. - 23 Hz
Gewicht - 65.1
GRUPPE1 - Displays
GRUPPE2 - Led Large Format
GTIN - 5028695125247
guarantee - 36
guarantee_type - external
Height - 1099.1 mm
Height adjustment - No
HERSTELLER - SHARP NEC
Hoehe - 0.23
HSTNUMMER - 60005067
I/O connectors - 1 x 3,5 mm minijack
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB (Type B)
I/O connectors - 2 x DisplayPort
I/O connectors - 2 x HDMI
I/O connectors - 2 x USB 2.0
Laenge - 2.1
LongDesc - Intuitive professional content deliveryGreat first impressions can make all the difference; presenting your business in the best possible way will boost your brand. With slim, modern styling, 24/7 operation and high haze panel to reduce reflections when ambient light is high, the M series is the professional way to deliver your message, yet at an attractive price point.With the optional NEC MediaPlayer or the more powerful Intel® Smart Display Module (Intel® SDM) computing device, you are primed and ready for intuitive signage creation delivering real-time media playback for exceptional visual experiences. For advertising, infotainment and meeting room applications, the M Series provides powerful, upgradable functionality and all the aesthetic appeal to effortlessly reflect your brand credentials.
LongProductName - 86", 3840 x 2160 px, IPS, 500 cd/m2, 8 ms, 100-240 V / 50-60 Hz, 19276 x 1099.1 x 83.2 mm, 47 kg
LongSummaryDescription - NEC MultiSync M861. Product design: Digital signage flat panel. Display diagonal: 2.18 m (86"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD. Operating hours (hours/days): 24/7. Product colour: Black
Matrix type - TFT IPS
Model - M861
name - MultiSync M861 large format monitor 86 inch UHD 24/7 500cd/m2
Number of colors - 1,07 mld
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 80%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Optional accessory -
Other features -
Packaging content - Batteries included - Yes
Packaging content - Cables included - HDMI, Power
Packaging content - Remote control included - Yes
Packaging data - Package depth - 225 mm
Packaging data - Package height - 1225 mm
Packaging data - Package weight - 65.1 kg
Packaging data - Package width - 2090 mm
Performance - HDCP - Yes
Performance - Operating hours (hours/days) - 24/7
Performance - Purpose - Universal
Ports & interfaces - DisplayPorts in - 2
Ports & interfaces - DisplayPorts out - 1
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - Ethernet LAN - Yes
Ports & interfaces - Ethernet LAN data rates - 100 Mbit/s
Ports & interfaces - HDMI input ports quantity - 2
Ports & interfaces - HDMI output ports quantity - 1
Ports & interfaces - HDMI ports quantity - 3
Ports & interfaces - USB port - Yes
Ports & interfaces - USB ports quantity - 3
Ports & interfaces - USB version - 2.0
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Energy consumption (SDR) per 1000 hours - 193 kWh
Power - Energy efficiency class (SDR) - G
Power - Power consumption (typical) - 320 W
Power consumption - 193 kW
producer - NEC
ProductName - M861
Refresh rate - 60 Hz
Resolution - 3840 x 2160
Response time - 8 ms
Screen size (diag.) - 86''
ShortSummaryDescription - NEC MultiSync M861, Digital signage flat panel, 2.18 m (86"), LCD, 3840 x 2160 pixels, 24/7
Speakers built-in - Yes
Static contrast - 8 000:1
Stck_Kart - 1
Stck_Pal - 0
Storno - Y
Title - NEC MultiSync M861 Digital signage flat panel 2.18 m (86") LCD 500 cd/m² 4K Ultra HD Black 24/7
Touch screen - No
Transreflective technology - LED
TV tuner built-in - No
URL - https://www.sharpnecdisplays.eu/p/uk/en/products/details/t/large-format-displays/midrange-displays/rp/m861.xhtml
vendpn - 60005067
VESA - 600 x 400
Viewing angle, horizontal - 178 °
Viewing angle, vertical - 178 °
Warranty -
WarrantyInfo - 3 years warranty incl. backlight
Web camera - None
Weight - 47 kg
Weight & dimensions - Depth - 83.2 mm
Weight & dimensions - Height - 1099.1 mm
Weight & dimensions - Weight - 47 kg
Weight & dimensions - Width - 1927.6 mm
Width - 1927.6 mm
WiFi - No
