Iiyama T6562AS-B1

ARTIKEL1 - T6562AS-B1 65IN 165.10CM UHD IP
ARTIKEL2 - 3840X2160 400CD/M ANTIGLARE
Audio - Yes
Audio - Built-in speaker(s) - Yes
Audio - Number of built-in speakers - 2
Audio - RMS rated power - 20 W
AudioFeatures - 2 x 10W
Brand - iiyama
BrandPartCode - T6562AS-B1
Breite - 1
Brightness - 500 cd/m2
Camera - No
Category - Signage Displays
Computer system - Built-in processor - Yes
Computer system - Computer system - Yes
Computer system - Internal memory - 2 GB
Computer system - Internal storage capacity - 16 GB
Computer system - On-board graphics card model - ARM Mali-G51
Computer system - Operating system installed - Android 8.0
ContrastRatio - 1200:1
ContrastRatioDynamic - -
Depth - 71.8 mm
Design - Orientation - Horizontal/Vertical
Design - Panel mounting interface - 400 x 400 mm
Design - Placement supported - Indoor
Design - Product colour - Black
Design - Product design - Interactive flat panel
Design - VESA mounting - Yes
Display - Active display area (W x H) - 1422.4 x 802.6 mm
Display - Contrast ratio (typical) - 1200:1
Display - Display brightness - 500 cd/m²
Display - Display diagonal - 163.8 cm (64.5")
Display - Display diagonal (metric) - 164 cm
Display - Display number of colours - 1.07 billion colours
Display - Display resolution - 3840 x 2160 pixels
Display - Display technology - IPS
Display - HD type - 4K Ultra HD
Display - Horizontal scan range - 30 - 135 kHz
Display - Multi-touch - Yes
Display - Native aspect ratio - 16:9
Display - Number of simultaneous touchpoints - 20
Display - Pixel pitch - 0.372 x 0.372 mm
Display - Response time - 8 ms
Display - RGB colour space - NTSC
Display - Touchscreen - Yes
Display - Touchscreen technology - Capacitive
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
DisplayCaseColour - Black
DisplayFeatures -

AG coating

Light transmittance: 84%

Color support: 1.07B (8 Bits+FRC) (NTSC 72%)

Software: Android 8.0, Signal FailOver

CPU: CA73*2 + A53*2

GPU: MALI G51

Storage: 16GB eMMC

Memory: 2GB RAM + 1GB Embedded

Kiosk mode

Max. non-stop operating time: 24/7

Anti image retention

Glass thickness: 2.5mm, hardness: 6H

DisplayFormat - 16:9
DisplayNativeResolution - 3840 x 2160
DisplayPort - No
DisplaySizecm - 164 cm
DisplayType - LED IPS
DisplayViewingArea - 1427.5 x 802.6 mm
EANCode - 4948570120482
EmissionStandard - -
EPEAT - -
Ethernet - Yes
Frequency - 30-135 kHz
FrequencyV - 60 Hz
Gewicht - 23.42
GrossWeight - 46.000 kg
GRUPPE1 - Displays
GRUPPE2 - Lcd Touchscreen
GTIN - 4948570120482
HDMI - 3
Height - 860 mm
HeightAdjustment - No
HERSTELLER - IIYAMA CONSIGNMENT
Hoehe - 0
HSTNUMMER - T6562AS-B1
InputSignal -

3x HDMI

>RJ-45

2x IR

2x RS-232c

2x USB 2.0

microSD

KensingtonLock - -
Laenge - 1.64
LongDesc -
LongDesc - PROLITE T6562AS-B1All-in-one PCAP Interactive Display inspired by technology and designed for creative spaces and sharing.Enjoy an all-in-one interactive display that combines the best in PCAP Touchscreen technology, offering the versatility and freedom of Android OS, easily customized to your needs by installing applications directly to it. Offering a powerful, yet flexible user experience, fostering creative communication with the benefits of a secure and controllable Touchscreen.The refined design of the T6562AS-B1 lends itself for integration into a large variety of environments where polished design and functionality are needed, like Huddle spaces in the modern office space, Retail shops and Kiosks.RETAIL INSTALLATIONSThe interactive 4K Touchscreens are the key for immersive interactive experiences for spatial retail design. Allow customers to explore your website right there and then or engage with a range of creative or experiential applications you want to host. The flexibility of either landscape or portrait modes with 24/7 Operation, built-in Android and MediaPlayer make the 62 Series displays one of the most adaptable Touchscreens solutions around.HUDDLE SPACESTurn these small meeting rooms into neat Collaboration spaces by employing the embedded applications like Android OS, EShare and Whiteboard, a selection of intuitive and practical tools installed on our PCAP interactive Touchscreens. With Android OS you can easily customize the display by installing applications directly to it. With the EShare app you can share, stream and edit content from any device directly on screen and transform your team meetings into an easy, fast and seamless interactive session.SIGNAL FAILOVERFailOver is a feature which automatically detects input sources. When there is no signal on the default input it will automatically switch to the next available input. FailOver allows customers to prioritize a number of inputs (incl. Browser, Media Player and Custom) and ensures your content is always actively displayed, assuring active content at all times.ANDROID OSThanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.TOUCH TECHNOLOGY - CAPACITIVEThis technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.
LongProductName - 64.5", 3840 x 2160, IPS, 16:9, 8 ms, HDMI, RS-232C, RJ-45, USB, 1485 x 860 x 71.8 mm
LongSummaryDescription - iiyama T6562AS-B1. Product design: Interactive flat panel. Display diagonal: 163.8 cm (64.5"), Display technology: IPS, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD, Touchscreen. Operating hours (hours/days): 24/7. Operating system installed: Android 8.0. Product colour: Black
MANUFDATASHEET - https://iiyama.com/gl_en/products/prolite-t6562as-b1/
MonitorControls -

Touch technology: projective capacitive

Touch points: 20

Touch method: finger, glove

Touch interface: USB

MonitorSize - 64.5"
MonitorType - Interactive
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
PackageContents -

Cables: power, USB, HDMI, RS-232c

Quick start guide

Safety guide

Remote control (batteries included)

Packaging content - Cables included - AC, HDMI, RS-232, USB
Packaging content - Remote control included - Yes
Packaging data - Package depth - 223 mm
Packaging data - Package height - 1021 mm
Packaging data - Package weight - 46 kg
Packaging data - Package width - 1649 mm
Performance - HDCP - Yes
Performance - HDCP version - 2.2
Performance - Mean time between failures (MTBF) - 50000 h
Performance - Number of OSD languages - 8
Performance - On Screen Display (OSD) - Yes
Performance - On Screen Display (OSD) languages - German, Dutch, English, Spanish, French, Japanese, Polish, Russian
Performance - Operating hours (hours/days) - 24/7
Performance - Purpose - Universal
Pivot - No
Pixelpitch - 0.372 mm
Ports & interfaces - DVI port - No
Ports & interfaces - Ethernet LAN - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI ports quantity - 3
Ports & interfaces - RS-232C - Yes
Ports & interfaces - USB port - Yes
Ports & interfaces - USB ports quantity - 2
Ports & interfaces - USB version - 2.0
Ports & interfaces - Wi-Fi - No
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 1.5 W
Power - Power consumption (typical) - 165 W
ProdDesc - Iiyama PROLITE T6562AS-B1 - Diagonal, 64.5" - 164cm ; Panel, IPS LED, AG Coating ; Native resolution, 3840 x 2160 (8.3 MegaPixels 4K UHD) ; Aspect ratio, 16:9 ; Panel brightness, 500 cd/m²
ProductName - T6562AS-B1
ProductPicture - http://www.tdbaltic.ee/images/ds4/T6562AS-B1-01.jpg
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
ResponseTime - 8 ms
Rotate - No
ShortSummaryDescription - iiyama T6562AS-B1, Interactive flat panel, 163.8 cm (64.5"), IPS, 3840 x 2160 pixels, 24/7
Stck_Kart - 1
Stck_Pal - 0
Storno - Y
Technical details - Compliance certificates - CE, REACH, RoHS, WEEE
Technical details - Pallet net height - 13 cm
Technical details - Pallet net length - 114 cm
Technical details - Pallet net width - 166 cm
Technical details - Sustainability certificates - ErP
Tilt - No
Title - iiyama T6562AS-B1 Signage Display Interactive flat panel 163.8 cm (64.5") IPS 500 cd/m² 4K Ultra HD Black Touchscreen Built-in processor Android 8.0 24/7
URL - https://iiyama.com/gl_en/products/prolite-t6562as-b1/
USB - 2
USBTypeC - No
VESACompatible - Yes
VESAStandard - 400 x 200
ViewingAngle - 178
ViewingAngleV - 178
Warranty - 3 years
WarrantyInfo -
Weight - 38.400 kg
Weight & dimensions - Depth - 71.8 mm
Weight & dimensions - Height - 860 mm
Weight & dimensions - Weight - 38.4 kg
Weight & dimensions - Width - 1485 mm
Width - 1485 mm
Wireless - No
WirelessFeatures - -
