Accessories included -
Accessories included - Videobar Teams for medium-sized rooms 1x A30 all-in-one Collaboration bar, power supply, wall bracket and cables 1x CTP18 touch console, PoE power supply, wall bracket and cables 2-year hardware warranty
Audio - Audio system full duplex - Yes
Audio - Built-in speaker(s) - Yes
Audio - Echo cancellation - Yes
Audio - Number of speakers - 1
Audio - RMS rated power - 5 W
Brand - Yealink
BrandPartCode - 1206653
Camera - Camera type - Dual camera
Camera - Field of view (tele) - 90°
Camera - Field of view (wide) - 120°
Camera - Megapixel (approx.) - 8 MP
Camera - Second camera resolution - 8 MP
Category - Video Conferencing Systems
Category 1 - Multimedia
Category 2 - Konferenzsysteme
Certificates - Certification - CE, FCC, RoHS, REACH, ISO 9001, CCC, NOM
Color - Black
Compatible with -
Computer system - Operating system installed - Android 10
Computer system - Processor family - Qualcomm Snapdragon
Computer system - Processor model - 845
Description - The Yealink A30 Teams is a versatile all-in-one videoterminal dedicated to medium-sized rooms and meeting rooms. Equipped with an 8 MP camera and 120° wide-angle lens, the A30 delivers exceptional video quality. The A30 also features automatic lens aperture and the ability to frame and track the speaker as a direct result of its AI technology. The 8 MEMS microphones and noise cancellation algorithm, provide an excellent audio experience in medium-sized rooms. Every participant in the meeting can be clearly seen and heard. The CTP18 is a collaborative touch panel designed for small and medium-sized rooms. Its 8-inch touchscreen and user-centred interactive design enable users to join or control a meeting quickly and effortlessly. This significantly reduces the difficulty of using a video conferencing system and provides a better meeting experience. When the CTP18 works with the Yealink Wireless Presentation Pod WPP20, you can annotate or control shared content directly on the CTP18, improving communication efficiency.
dimension depth - 800 mm
dimension height - 230 mm
Dimensions - 202 x 151 x 100 mm
Dimensions - 700 x 98 x 121 mm
dimension weight - 8100 g
dimension width - 446 mm
Display - Display diagonal - 20.3 cm (8")
Display - Display resolution - 1280 x 800 pixels
Display - Touchscreen - Yes
ean - 6938818314993
EAN - 6938818314993
Features - Cable lock slot - Yes
Features and Functions - built-in microphone
Features and Functions - digital zoom
Features and Functions - face tracking feature
GTIN - 6938818314993
guarantee - 24
guarantee_type - normal
Interface - USB
LongDesc - Yealink MeetingBar A30 is an all-ine-one video bar deisgned for medium space (up to 15, with additional extended wireless mic. VCM36). The dual-camera system catches details in a medium room precisely, with great color. AI-powered features including Auto Framing, Speaker Tracking, Picture-in-Picture and Smart Gallary deliver a focused view without distraction. The built-in 8-MEMS beamforming microphones pick up voice from all directions, and a full-duplex audio algorithm with AI-enhanced noise cancellation delivers clear sound for both sides clearly even if you are talking at the same time.
LongProductName - MeetingBar A30-020 - all-in-one video bar - Teams/Zoom/BYOD - AI-powered view - noise cancellation - video conferencing kit (video bar, touch console CTP18)
LongSummaryDescription - Yealink MeetingBar A30-020. Product type: Video collaboration bar. Ethernet LAN, Wi-Fi. Bluetooth. Display diagonal: 20.3 cm (8"), Display resolution: 1280 x 800 pixels. Operating system installed: Android 10. Product colour: Black
Manufacturer - Yealink
Microphone - Microphone mute - Yes
Microphone - Number of microphone arrays - 8
MPN - 1206653
name - Videobar A30-020 + control panel
Name - Yealink A30-020 Meetingbar
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Networking standards - IEEE 802.1x
Network - Security algorithms - 256-bit AES, EAP-MD5, EAP-TTLS, PEAP, SRTP, TLS
Network - VLAN support - Yes
Network - Wi-Fi - Yes
Operational conditions - Operating relative humidity (H-H) - 10 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -30 - 70 °C
Other features - Ekran 8-calowy pojemnościowy ekran dotykowy IPS FHD Rozdzielczość 1280 x 800 (16:10) Dotyk 10-punktowy wielodotykowy Interfejs: 1 x USB-C do debugowania urządzenia, 1 x Ethernet RJ45 do zasilania i połączenia danych, 1 x gniazdo resetowania Sieć bezprzewodowa: Wi-Fi Wi-Fi 2,4G/5G, IEEE 802.11n/ac , obsługa połączeń z siecią Wi-Fi generowaną wyłącznie przez punkty końcowe Yealink VCS
Other features - Video 8MP camera Wide 120° angle of view 4x e-PTZ Second camera 8MP 90° angle of view 10x hybrid zoom (3.5x optical, 3x digital) Automatic lens iris Speaker tracking and framing Audio 8 built-in MEMS microphones Connection possibility for additional microphones Two 5-watt high fidelity speakers Yealink Noise Proof Technology Directional voice pickup technology Full-duplex Echo cancellation
Packaging content - AC adapter included - Yes
Packaging content - Cables included - HDMI, LAN (RJ-45)
Packaging content - HDMI cable length - 1.8 m
Packaging content - Networking cable length - 3 m
Packaging content - Quick start guide - Yes
Performance - Auto framing - Yes
Performance - Bluetooth - Yes
Performance - Meeting features - Add participates, Calendar, Content sharing, Hold/Resume, One-click join, Whiteboard
Performance - Product colour - Black
Performance - Product type - Video collaboration bar
Performance - PTZ control - Yes
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI input ports quantity - 1
Ports & interfaces - HDMI output ports quantity - 2
Ports & interfaces - Line-in - Yes
Ports & interfaces - Line-out - Yes
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - USB connector type - USB Type-A, USB Type-C
Power - AC input voltage - 100 - 240 V
Power - DC output current - 0.7 A
Power - DC output voltage - 48 V
Power - Power consumption (idle) - 13 W
Power - Power consumption (typical) - 10.5 W
Power - Power source type - AC
producer - Yealink
ProductName - MeetingBar A30-020
Sensor -
Separator - 11760Panel sterowania CTP18]]>1
Separator - 11760Videobar A30 camera]]>Kamera wideobar A30]]>0
ShortSummaryDescription - Yealink MeetingBar A30-020, Video collaboration bar, Android 10, Black
Software included -
Title - Yealink MeetingBar A30-020
URL - https://www.yealink.com/en/product-detail/microsoft-teams-rooms-meetingbar-a30
Use - Average hall
vendpn - 1206653
Video - Video codecs - H.264 High profile, H.264 SVC, H.264
WarrantyInfo -
Weight - 8.42
Weight & dimensions - Depth - 98 mm
Weight & dimensions - Height - 121 mm
Weight & dimensions - Width - 700 mm
