Imou NET VIDEO RECORDER 8CH/NVR1108HS-W-S2

15pin D-sub Input/Output connectors - 1
Brand - Dahua Technology
BrandPartCode - DHI-NVR1108HS-W-S2-CE
Category - Network Video Recorders (NVR)
Category Code - NVR
CnCode CnCode - 85219000
Description - The Wireless Recorder is used to record videos and secure your home or business. Without the limitation of the network cable, cameras connect to the recorder via Wi-Fi, and could be placed freely in any corner.
Dimensions - 260.3mm×247.3mm×44.7mm
Features - LED indicators - HDD, Network, Power
Features - Product colour - Black
Features - Rack capacity - 1U
Features - Rack mounting - Yes
Full Description Line - Channels 8|1x15pin D-sub|1xHDMI|2xRCA|1xUSB 2.0|1xRJ45|Included Accessories - 1 x Quick Start Guide;- 1 x Power Adapter;- 1 x Network Cable;- 1 x Screw Package;- 1 x Mouse|Power supply requirements DC12V 1.5A|Power consumption 10 Watts|Dim. 260.3mm×247.3mm×44.7mm|Temp. range -10℃～+45℃(+14℉~+104℉)
GTIN - 6923172543004
GTIN - 6939554982897
Hard drive - HDD interface - SATA
Hard drive - Maximum storage capacity - 16 TB
Hard drive - Number of HDDs installed - 1
HDMI Input/Output connectors - 1
Included Accessories - - 1 x Quick Start Guide;
- 1 x Power Adapter;
- 1 x Network Cable;
- 1 x Screw Package;
- 1 x Mouse
LongDesc - Series OverviewWith its embedded Wi-Fi module, Dahua's Lite Series Wireless Recorder supports the AP function, and automatically detects and connects with Dahua wireless cameras. It has two antennas that together produce strong wireless signals, and has IEEE 802.11 b/g/n (2.4G Hz) Wi-Fi which allows it to cover a wider area. This NVR also supports the access of IP cameras, making installation more convenient.Without the limitation of network cables, the wireless recorder combined with the Dahua wireless camera provides a great solution for SMB surveillance systems, making this NVR ideal for a wide range of applications including home safety, cafes, supermarkets, retail, education and more industries.New User InterfaceHighly user friendly, the new web interface and GUI have a minimalist flat design, that makes navigating the system much easier. The functional modules have also been arranged to be clearer and easier to understand.Automatic Wireless PairingIn just 120 seconds, the wireless NVR automatically pairs with the wireless IPC after the system starts up, allowing you to work faster and more efficiently.Wireless CascadingThe wireless NVR automatically cascades IPCs for long-distance surveillance.
LongProductName - 8 Channel Compact 1U 1HDD Network Video Recorder
LongSummaryDescription - Dahua Technology CAMERA RECORDER BLACK. Video input channels: 8 channels, Video recording modes: 720p, 1080p, Operating system installed: Embedded LINUX. Maximum storage capacity: 16 TB, HDD interface: SATA. Ethernet LAN data rates: 10,100 Mbit/s, Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; Alarm Server; P2P. Rack capacity: 1U, LED indicators: HDD, Network, Power, Product colour: Black. Output current: 1.5 A, Output voltage: 12 V
Model - NVR1108HS-W-S2
Number of Channels - 8
Operating temperature range - -10℃～+45℃(+14℉~+104℉)
Operational conditions - Operating relative humidity (H-H) - 10 - 93%
Operational conditions - Operating temperature (T-T) - -10 - 45 °C
Performance - Audio codecs - PCM; G711A; G711U; G726
Performance - Backup function - Yes
Performance - Multi-screen - Yes
Performance - Operating system installed - Embedded LINUX
Performance - Playback modes - Pause, Play, Stop
Performance - Video codecs - Smart H.265; H.265; Smart H.264; H.264; MJPEG
Performance - Video input channels - 8 channels
Performance - Video motion detection - Yes
Performance - Video recording modes - 720p, 1080p
Ports & interfaces - Audio RCA inputs - 1
Ports & interfaces - Audio RCA outputs - 1
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Ethernet LAN data rates - 10,100 Mbit/s
Ports & interfaces - HDMI output - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - Supported network protocols - HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; Alarm Server; P2P
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - VGA (D-Sub) output ports - 1
Power - Output current - 1.5 A
Power - Output voltage - 12 V
Power consumption - 10 Watts
Power supply requirements - DC12V 1.5A
Processor - Built-in processor - Yes
ProductName - CAMERA RECORDER BLACK
RCA Input/Output connectors - 2
RJ45 Input/Output connectors - 1
Shipping Box Depth Shipping/Package Box Dimensions - 37 cm
Shipping Box Height Shipping/Package Box Dimensions - 30.5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 1.6 kg
Shipping Box Width Shipping/Package Box Dimensions - 12 cm
ShortSummaryDescription - Dahua Technology CAMERA RECORDER BLACK, 8 channels, 720p, 1080p, Embedded LINUX, Smart H.265; H.265; Smart H.264; H.264; MJPEG, PCM; G711A; G711U; G726, Pause, Play, Stop
System requirements - Browser supported - Chrome; IE 9 or later; Firefox
System requirements - Mobile operating systems supported - Android, iOS
Title - Dahua Technology CAMERA RECORDER BLACK 1U
Unit Box Height - 0.305
Unit Box Length - 0.37
Unit Box Width - 0.12
Unit Brutto Volume - 0.01354 cubm
Unit Gross Weight - 1.6 kg
Unit Net Weight - 0.824 kg
URL - https://www.dahuasecurity.com/products/
USB 2.0 Input/Output connectors - 1
Vendor Homepage - www.imoulife.com/public/asset/files/NVR_Datasheet.pdf
Warranty - 24 months
WarrantyInfo -
Weight & dimensions - Depth - 247.3 mm
Weight & dimensions - Height - 44.7 mm
Weight & dimensions - Package depth - 117 mm
Weight & dimensions - Package height - 308 mm
Weight & dimensions - Package weight - 1.56 kg
Weight & dimensions - Package width - 372 mm
Weight & dimensions - Weight - 824 g
Weight & dimensions - Width - 260.3 mm
