Audio - Audio codecs - G.711a, G.711Mu, G726
Audio - Audio detection - Yes
Audio - Built-in loudspeaker - No
Audio - Built-in microphone - Yes
Audio - Signal-to-Noise Ratio (SNR) - 56 dB
Audio - Two-way talk - N
Audio - Voice codecs - G.711a
Audio - Voice codecs - G.711Mu
Audio - Voice codecs - G.711Mu, G.711a, G.726, PCM
Audio - Voice codecs - G.726
Audio - Voice codecs - PCM
Brand - Dahua Technology
BrandPartCode - 1.0.01.04.39366-0030
Camera - Adjustment shutter speed - Auto/Manual
Camera - Angle of rotation - 355°
Camera - Camera pan control - Yes
Camera - Camera shutter speed - 1/3 - 1/100000 s
Camera - Camera shutter type - Electronic
Camera - Camera tilt control - Yes
Camera - Horizontal rotation angle - 0 - 355°
Camera - Lens viewing angle, diagonal - 121°
Camera - Lens viewing angle, horizontal - 102°
Camera - Lens viewing angle, vertical - 54°
Camera - Minimum illumination - 0.006 lx
Camera - Motion detection - Yes
Camera - Number of Privacy masking areas - 4
Camera - Pan range - 0 - 355°
Camera - People detection - Yes
Camera - Tilt angle range - 0 - 65°
Camera - Vertical rotation angle - 0 - 65°
Camera - Viewing angle, diagonal - 121°
Camera - White balance - Auto
Camera - White balance - Auto, Manual, Natural, Outdoor, Regional custom, Street lamp
Camera - White balance - Manual
Camera - White balance - Natural
Camera - White balance - Outdoor
Camera - White balance - Regional custom
Camera - White balance - Street lamp
Category - Security Cameras
Design - Degree of protection IK - IK10
Design - Form factor - Dome
Design - Form factor - Tube/dome
Design - Housing material - Metal
Design - Housing material - Metal, Plastic
Design - IK code - IK10
Design - International Protection (IP) code - IP67
Design - Mounting type - Ceiling
Design - Mounting type - Wall/ceiling
Design - Product colour - Black
Design - Product colour - White
dimensionalWeight - 454
dimensionalWeight - 470
Image sensor - Number of sensors - 1
Image sensor - Optical sensor size - 25.4 / 2.9 mm (1 / 2.9")
Image sensor - Progressive scan - Yes
Image sensor - Sensor type - CMOS
Lens system - Closest focusing distance - 1.1 m
Lens system - Detect distance - 63.6 m
Lens system - Fixed focal length - 2.8 mm
Lens system - Fixed focus - Yes
Lens system - Focal length range - 2.8 mm
Lens system - Identify distance - 6.4 m
Lens system - Lens type - Fixed focal length lens
Lens system - Maximum aperture number - 1.6
Lens system - Number of lenses - 1
Lens system - Observe distance - 25.4 m
Lens system - Recognize distance - 12.7 m
LongDesc - IPC-HDBW2441E-S4MP IR Fixed-focal Dome WizSense Network CameraLaunched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.
LongProductName - 4MP 1/2.9" CMOS, 128 MB RAM, 128 MB ROM, F1.6, f: 2.8mm, RJ-45 (10/100 Base-T), 81.0 mm × Φ109.9 mm
LongSummaryDescription - Dahua Technology WizSense DH-IPC-HDBW2441E-S-Black. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: Black, Form factor: Dome. Angle of rotation: 355°, Lens viewing angle, horizontal: 102°, Lens viewing angle, vertical: 54°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.9 mm (1 / 2.9"). Detect distance: 63.6 m, Observe distance: 25.4 m, Recognize distance: 12.7 m
Management features - Web-based management - Yes
Management features - Web browser - Yes
Network - 4G LTE - N
Network - Bluetooth - No
Network - Ethernet interface type - 10 Megabit Ethernet
Network - Ethernet interface type - 100 Megabit Ethernet
Network - Ethernet interface type - Fast Ethernet
Network - Ethernet LAN - Yes
Network - Networking standards - IEEE 802.3af
Network - Supported network protocols - IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP
Network - Wi-Fi - No
Night vision - LED type - IR
Night vision - Night vision - Yes
Night vision - Night vision distance - 30 m
Night vision - Number of illumination LEDs - 3
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -40 - 60 °C
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Packaging content - Number of cameras - 1
Packaging data - Package weight - 490 g
Performance - Certification - CE-LVD: EN62368-1;
CE-EMC: 2014/30/EU;
FCC: 47 CFR FCC Part 15, B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14
Performance - Connectivity technology - Wired
Performance - Placement supported - Indoor & outdoor
Performance - Placement supported - Outdoor
Performance - Signal-to-Noise Ratio (SNR) - 56 dB
Performance - Type - IP security camera
Performance - Wide Dynamic Range (WDR) - 120 dB
Performance - Wide Dynamic Range (WDR) - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - DC output voltage - 12
Power - Power consumption (max) - 5 W
Power - Power consumption (Power over Ethernet (PoE)) - 2.9 W
Power - Power consumption (Power over Ethernet (PoE)) - 6 W
Power - Power consumption (typical) - 2.3 W
Power - Power consumption (typical) - 5 W
Power - Power source type - DC, PoE
producerCode - IPC-HDBW2441E-S
producerCode - IPC-HDBW2441E-S-0280B
productName - Dahua Technology WizSense DH-IPC-HDBW2441E-S Dome IP security camera Indoor & outdoor 2688 x 1520 pixels Ceiling
ProductName - DH-IPC-HDBW2441E-S-Black
productName - IP Camera DAHUA IPC-HDBW2441E-S-0280B White
productSize - Normal
Security - Active tampering alarm - Yes
Security - Intelligent Video Surveillance (IVS) system features - Intrusion
Security - Intelligent Video Surveillance (IVS) system features - Intrusion, Tripwire
Security - Intelligent Video Surveillance (IVS) system features - Tripwire
Security - IP address filtering - Yes
Security - Mirror - Yes
Security - Video motion detection - Yes
ShortSummaryDescription - Dahua Technology WizSense DH-IPC-HDBW2441E-S-Black, IP security camera, Indoor & outdoor, Wired, CE-LVD: EN62368-1; CE-EMC: 2014/30/EU; FCC: 47 CFR FCC Part 15, B; UL/CUL: UL62368-1 & CAN/CSA..., Ceiling, Black
sizeX - 140
sizeY - 120
sizeY - 140
sizeZ - 116
sizeZ - 140
Storage - Built-in HDD - No
Storage - Card reader integrated - Yes
Storage - Compatible memory cards - MicroSD (TransFlash)
Storage - Compatible memory cards - MicroSDHC
Storage - Compatible memory cards - MicroSDXC
Storage - Internal memory - 128 MB
Storage - Maximum memory card size - 256 GB
Storage - RAM capacity - 128 MB
Storage - ROM capacity - 128 MB
System requirements - Mobile operating systems supported - Android
System requirements - Mobile operating systems supported - iOS
Title - Dahua Technology WizSense DH-IPC-HDBW2441E-S-Black Dome IP security camera Indoor & outdoor 2688 x 1520 pixels Ceiling
URL - https://www.dahuasecurity.com/es/products/All-Products/Network-Cameras/WizSense-Series/2-Series/4MP/IPC-HDBW2441E-S
Video - Back Light Compensation (BLC) - Yes
Video - Bit rate - 12 kbps–6144 kbps
Video - Bit rate control - Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Video - Frame rate - 20 fps
Video - Frame rate - 30 fps
Video - Gain control type - Auto/Manual
Video - Highlight Compensation (HLC) - Yes
Video - Maximum resolution - 2688 x 1520 pixels
Video - Noise reduction - Yes
Video - Noise reduction technology - 3D noise reduction
Video - Region of Interest (ROI) encoding - Yes
Video - Supported graphics resolutions - 352 x 240
Video - Supported graphics resolutions - 352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2688 x 1520
Video - Supported graphics resolutions - 352 x 288
Video - Supported graphics resolutions - 640 x 480 (VGA)
Video - Supported graphics resolutions - 704 x 480
Video - Supported graphics resolutions - 704 x 576
Video - Supported graphics resolutions - 1280 x 720 (HD 720)
Video - Supported graphics resolutions - 1280 x 960
Video - Supported graphics resolutions - 1920 x 1080 (HD 1080)
Video - Supported graphics resolutions - 2304 x 1296
Video - Supported graphics resolutions - 2560 x 1440
Video - Supported graphics resolutions - 2688 x 1520
Video - Total megapixels - 4 MP
Video - Video compression formats - H.264
Video - Video compression formats - H.264+
Video - Video compression formats - H.264, H.264+, H.264B, H.264H, H.265, H.265+, M-JPEG
Video - Video compression formats - H.264B
Video - Video compression formats - H.264H
Video - Video compression formats - H.265
Video - Video compression formats - H.265+
Video - Video compression formats - M-JPEG
Video - Video streaming - Yes
WarrantyInfo -
warrantyLength - 36
warrantyType - F
warrantyType - G
weight - 510
weight - 519
Weight & dimensions - Depth - 109.9 mm
Weight & dimensions - Diameter - 11 cm
Weight & dimensions - Height - 81 mm
Weight & dimensions - Weight - 340 g
Weight & dimensions - Width - 109.9 mm
