Sapphire Radeon RX 7700 XT, 12GB GDDR6, NITRO+

2D/3D Features - AMD FreeSync AMD Radeon Super Resolution AMD Software: Adrenalin Edition AMD Noise Suppression AMD Privacy View AMD Infinity Cache AMD Radiance Display Engine AMD FidelityFX Super Resolution AMD RDNA 3 Architecture
Accessories included -
ARTIKEL1 - NITRO+AMD RADEON RX 7700XT GAM
ARTIKEL2 - OC 12GB GDDR6 DUAL HDMI DUAL DP
BIOS Features - Dual BIOS
Box Weight Brutto (kg) - 8 kg
Breite - 0.25
Card's length - > 280 mm
Card Slot Width - 3 slot
category - PC Components|Graphics Cards|AMD
Category Code - VGP
Category_1 - Graphics Cards
Category_2 - Graphics Cards PCIe - AMD
Chipset - AMD Radeon RX 7700 XT
Chipset - Radeon RX 7700 XT
Chipset manufacturer - AMD
code - 11335-02-20G
Compute Units Quantity - 54
Cooling - Active
Cooling System Type - Tri-X Cooling
Core Boost frequency - 2599 MHz
Core frequency - 2276 MHz
Depth (mm) - 320 mm
Description - BIOS Switch software Switch from performance mode to silent mode or back using our TriXX software to quickly and easily switch between dual BIOS modes. WAVE fin design and V-shaped fin design for GPU cooling The WAVE fin design reduces friction when wind enters the fin module, resulting in reduced wind noise. V-shaped fins on top of the GPU accelerate and centralize airflow around the GPU to dissipate heat efficiently. Cold rolled steel frame Experience the premium and beautifully crafted NITRO+ AMD Radeon RX 7700 Digital power design The SAPPHIRE NITRO+ AMD Radeon RX 7000 Series is designed with digital power that provides accurate power control and excellent energy efficiency High TG copper PCB The GPU is mounted on a 14-layer PCB board with 2oz copper thickness and high TG to match the high speed, high current and increased power requirements of the GPU and memory to guarantee the high stability of the PCB during operation. Durable metal backplate The all-aluminum backplate provides extra stiffness to ensure nothing flexes and dust stays out. It also helps cool the card by increasing heat dissipation. Dedicated VRM cooling Dedicated VRM cooling module ensures optimal heat dissipation for maximum airflow and cooling performance. Angular velocity fan blade Angular Velocity fan blades provide a double layer of downward air pressure which, together with the air pressure on the outer ring of the axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation than before generations. Very high performance, conductive, polymer capacitor The ultra-high-performance conductive aluminum polymer capacitor has a small PCB footprint but high volumetric capacitance that enables 14-phase power supply on the RX 7700 Series graphics card. The capacitor provides stable capacitance at high frequency and temperature with very low signal noise, ensuring stability and product reliability. Optimized composite heat pipe Composite heat pipes are precisely tailored to each individual cooling design, ensuring optimal heat flow, distributing heat efficiently and evenly throughout the cooling module. Fuse protection To protect your card, SAPPHIRE cards have a built-in fuse in the external PCI-E power connector circuit to ensure component safety. Support system fan control When the GPU temperature increases, the graphics card fans speed up accordingly. To further aid cooling and heat dissipation, the Assisted System Fan Control feature in SAPPHIRE's TriXX software controls the system fan speed to automatically increase at the same time as the graphics card fans, which helps remove heated air from the entire system faster Dual BIOS Choose between Basic BIOS mode or Secondary mode to enhance your gaming experience. Graphics card supporter Included is a graphics card bracket that holds the graphics card in place in the PCIe slot. ARGB light bar Thanks to the stylish design of the ARGB LED-enhanced cover, you can change the colors of the LEDs for a personalized design. This can be controlled via TriXX software. Choose from a variety of modes including fan speed mode, PCB temperature mode or colorful rainbow mode, or turn off the LEDs. External ARGB control synchronization Enable external RGB LED synchronization between the graphics card and motherboard via the 3-pin connector at the end. Players can then choose whether the graphics card will implement the RGB LED effects itself or whether the motherboard will take control of them. Quick fan connection If there is a problem with the fan, you do not need to return the entire card. SAPPHIRE or our sales partners will ship the replacement fan directly to you! This means they can be easily removed, cleaned and replaced, with just one screw holding them securely in place. Double ball bearing They are equipped with fans with double ball bearingsbearings, which in our tests have approximately 85% longer service life than plain bearings. Improvements to the fan blades mean the solution is up to 10% quieter than the previous generation. TRI-X COOLING TECHNOLOGY Clock Boost: up to 2599MHz Game clock: up to 2276 MHz The innovative combination of Robust VRM Cooling and independent memory thermal modules work together to efficiently and effectively remove heat from all sections Tunneled fins increase convective airflow and ensure continuous wind flow through the cooling and fan system Heat is dissipated by three large, efficient fans operating counterclockwise to maximize airflow.
Description - NITRO+ AMD Radeon™ RX 7700 XT 12GB - GPU: Boost Clock: Up to 2599 MHz - GPU: Game Clock: Up to 2276 MHz - Memory: 12GB/192 bit DDR6. 18 Gbps Effective - Stream Processors: 3456 - RDNA™ 3 Architecture - Ray Accelerator: 54
Design - Cooling technology - Sapphire Tri-X
Design - Cooling type - Active
Design - Illumination - Yes
Design - Illumination colour - Multi
Design - Number of fans - 3 fan(s)
Design - Number of slots - 3
Design - Product colour - Grey
dimensionalWeight - 1857
dimension depth - 90 mm
dimension height - 430 mm
Dimensions - 320 x 134.85 x 61.57 mm
Dimensions - 320(L)X 134.85(W)X 61.57 (H)mm
dimension weight - 2500 g
dimension width - 200 mm
DisplayPort Input/Output connectors - 2
DisplayPort Interface Quantity - 2
ean - 4895106294370
EAN - 4895106294370
EAN Code - 4895106294370
EANCode - 4895106294370
EAN_code - 4895106294370
External Power - 2 x 8 pin
Form Factor - Full-Size
Full Description Line - AMD Radeon RX 7700 XT|Graphics memory size 12 GB|GDDR6|192 bit|PCIE 4.0 16x|Memory CLK 18 Gbps|GPU boost clock 2599 MHz|7680x4320|2xHDMI|2xDisplayPort
Gewicht - 2.18
GPU boost clock - 2599 MHz
GPU Core Name - Navi 32
GPU Quantity - 1
Graphics card connector - PCI-E 16x ver. 4.0
Graphics connector - PCIE 4.0 16x
Graphics memory size - 12 GB
Graphics memory type - GDDR6
Gross Weight Kg - 1,2
GRUPPE1 - Multimedia & Games
GRUPPE2 - Video Card
guarantee - 36
guarantee_type - normal
HDMI Input/Output connectors - 2
HDMI Interface Connector Type - HDMI (Type A)
HDMI Interface Quantity - 2
Height (mm) - 61.57 mm
HERSTELLER - SAPPHIRE TECHNOLOGY
Hoehe - 0.09
HSTNUMMER - 11335-02-20G
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/230926140900373192.jpg
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/230926140912867658.jpg
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/230926140924047320.jpg
Included Accessories - Documentation
Installed Video Memory Storage Capacity - 1 x 12 GB
Laenge - 0.43
Manufacturer - Sapphire
Manufacturer Code - 11335-02-20G
Manufacturer Name - Sapphire
Manufacturer_code - 11335-02-20G
Max. Monitors Supports - 4
Maximum Resolution - 7680x4320
Max resolution - 7680x4320
Memory - Data transfer rate - TBA
Memory - Discrete graphics card memory - 12 GB
Memory - Graphics card memory type - GDDR6
Memory - Memory bus - 192 bit
Memory Bandwidth - 1 x 432 GB/s
Memory bus - 192 bit
Memory bus - 192-bit
Memory Bus Bandwidth - 1 x 192 bit
Memory CLK - 18 Gbps
Memory frequency - 18 Gbps
Memory Type - GDDR6 SDRAM
Memory type - DDR6
Model - 11335-02-20G
name - Graphics card Radeon RX 7700 XT NITRO+GAMING OC 12GB GDDR6 192bit 2DP
name - Sapphire Nitro+ Radeon RX 7700 XT Gaming OC, 12288 MB GDDR6
Name - SAPPHIRE Radeon RX 7700 XT NITRO+ GAMING OC 12G, graphics card (RDNA 3, GDDR6, 2x DisplayPort, 2x HDMI 2.1)
Other features -
Other information -
Package Type - Retail
Packaging data - Package type - Box
Packs in Box - 8
Pack Weight Brutto (kg) - 1 kg
Pack Weight Netto (kg) - 1 kg
Performance - AMD FreeSync - Yes
Performance - BIOS type - Dual UEFI
Performance - DirectX version - 1‎2 Ultimate
Performance - Dual Link DVI - No
Performance - TV tuner integrated - No
Performance - Virtual Reality (VR) ready - Yes
Pieces in pack - 1
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - DisplayPort version - 2.1
Ports & interfaces - HDMI ports quantity - 2
Ports & interfaces - Interface type - PCI Express x16 4.0
Power - Minimum system power supply - 700 W
Power - Supplementary power connectors - 2x 8-pin
Power connectors - 8+8 pin
Power consumption - 252 Watts
Power Consumption Operational - 252 W
Processor - CUDA - No
Processor - Graphics processor - Radeon RX 7700 XT
Processor - Graphics processor family - AMD
Processor - Infinity cache - 48 MB
Processor - Maximum displays per videocard - 4
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Parallel processing technology support - Not supported
Processor - Processor boost clock speed - TBA
Processor - Processor boost clock speed (Gaming mode) - TBA
Processor - Ray accelerators - 54
Processor - Stream processors - 3456
producer - Sapphire Technology
producerCode - 11335-02-20G
ProductCard - https://content.it4profit.com/itshop/itemcard_cs.jsp?ITEM=230814075250428896&THEME=asbis&LANG=lv
ProductCategory - Video kartes
ProductCode - 11335-02-20G
ProductDescription - SAPPHIRE NITRO+ AMD RADEON RX 7700 XT GAMING OC 12GB GDDR6 DUAL HDMI / DUAL DP
productName - SAPPHIRE Radeon RX 7700 XT NITRO+ GAMING OC 12GB GDDR6 graphics card
productSize - Normal
ProductType - Video Card
PSU Output Power Required - 700 W
Ray-tracing Cores Quantity - 1 x 54
Render Output Units Quantity (ROP) - 1 x 96
Requires Expansion Slot Standard - PCI Express 4.0 x16
Retail Packaging Net Weight Carton - 0.01 kg
Retail Packaging Net Weight Plastic - 0.01 kg
Shipping Box Depth Shipping/Package Box Dimensions - 43 cm
Shipping Box Height Shipping/Package Box Dimensions - 24 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 2.5 kg
Shipping Box Width Shipping/Package Box Dimensions - 9 cm
Short description - Sapphire VGA 12GB RX7700XT NITRO+ GAMING OC 2xHDMI/2xDP NITRO+ AMD RADEON RX 7700 XT GAMING OC 12GB GDDR6
sizeX - 240
sizeY - 430
sizeZ - 90
Stck_Kart - 8
Stck_Pal - 0
Storno - Y
Stream processors - 3456
Stream Processors Quantity - 1 x 3456
Supported standards - DirectX 12 Ultimate
Supported standards - OpenGL 4.6
System requirements - Linux operating systems supported - Yes
System requirements - Minimum RAM - 8192 MB
System requirements - Windows operating systems supported - Windows 10 x64
System requirements - Windows operating systems supported - Windows 11 x64
Texture Mapping Unit Quantity - 1 x 216
Unit Box Height - 0.24
Unit Box Length - 0.43
Unit Box Width - 0.09
Unit Brutto Volume - 0.009288 cubm
Unit Gross Weight - 2.5 kg
Unit Net Weight - 1.3 kg
Vendor - SAPPHIRE
Vendor Homepage - www.sapphiretech.com/en/consumer/nitro-radeon-rx-7700-xt-12g-gddr6
vendpn - 11335-02-20G
Version - Box
Video Card Features - RGB LED
Video Chipset - AMD Radeon RX 7700 XT
Video Memory Speed - 18 Gbps
Video Memory Type - Video Controller Memory
Video ports - 2 x DisplayPort
Video ports - 2 x HDMI
VRAM memory size - 12 GB
Warranty - 36 months
warrantyLength - 36
Warranty Products Returnable - Yes
Warranty Term (month) - 36 mēneši
warrantyType - G
Warranty validation Criteria - Serial Number
Weight - 2,17
weight - 2160
Weight & dimensions - Depth - 320 mm
Weight & dimensions - Height - 61.5 mm
Weight & dimensions - Width - 134.8 mm
Width (mm) - 134.85 mm
