Brand - Gigabyte
BrandPartCode - GV-N4090AERO OC-24GD
Card's length - > 280 mm
category -
Category - Graphics Cards
Category 1 - Grafikkarten
Category 2 - NVidia PCI-Express Grafikkarten
Category Code - VGP
Category_1 - Graphics Cards
Category_2 - Graphics Cards PCIe - Nvidia
Chipset - NVIDIA GeForce RTX 4090
code - GV-N4090AERO OC-24GD
Code - GV-N4090AERO OC-24GD
Cooling system - Dual Slot Fansink
CUDA Cores - 16384
Description - - NVIDIA Ada Lovelace Streaming Multiprocessors: Up to 2x performance and power efficiency - 4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering - 3rd Generation RT Cores: Up to 2X ray tracing performance - Powered by GeForce RTX™ 4090 - Integrated with 24GB GDDR6X 384-bit memory interface - WINDFORCE cooling system - RGB Fusion - Dual BIOS - Protection metal back plate - Anti-sag bracket
Design - Cooling type - Active
Design - Form factor - Full-Height/Full-Length (FH/FL)
Design - Illumination - Yes
Design - Number of fans - 3 fan(s)
Design - Product colour - White
Dimensions - L=342 W=150 H=75 mm
DisplayPort Input/Output connectors - 3
EAN - 4719331312916
ean - 4719331312916
EAN_code - 4719331312916
Full Description Line - NVIDIA GeForce RTX 4090|Graphics memory size 24 GB|GDDR6X|384 bit|PCIE 4.0 16x|Memory CLK 21 Gbps|GPU boost clock 2535 MHz|7680x4320|Cooling Dual Slot Fansink|1xHDMI|3xDisplayPort|Included Accessories 1. Quick guide2. Warranty registration3. Anti-sag bracket4. Anti-sag bracket installation guide5. One 16-pin to four 8-pin power adaptor
GPU boost clock - 2535 MHz
Graphics connector - PCIE 4.0 16x
Graphics memory size - 24 GB
Graphics memory type - GDDR6X
Gross Weight Kg - 2,9
GTIN - 0889523036624
GTIN - 889523036624
GTIN - 4719331312916
HDMI Input/Output connectors - 1
Included Accessories - 1. Quick guide
2. Warranty registration
3. Anti-sag bracket
4. Anti-sag bracket installation guide
5. One 16-pin to four 8-pin power adaptor
Link - https://www.gigabyte.com/Graphics-Card/GV-N4090AERO-OC-24GD#kf
LongDesc - WINDFORCE COOLING SYSTEMThe WINDFORCE cooling system features three 110mm unique blade fans, alternate spinning, 10 composite copper heat pipes, a large vapor chamber directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.ALTERNATE SPINNINGReduce the turbulence of adjacent fans and increase airflow pressure.3D ACTIVE FANThe 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.UNIQUE BLADE FANThe airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.GRAPHENE NANO LUBRICANTGraphene nano lubricant can extend the life of fan by 2.1 times, close to the life of double ball bearing, and is quieter.SCREEN COOLINGExtended heatsink design allows air flow to pass through, providing better heat dissipation.LARGE VAPOR CHAMBER & HEAT-PIPEThe large vapor chamber directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.RGB FUSIONWith 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.PROTECTION METAL BACK PLATEThe metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.DUAL BIOSThe factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience.POWER INDICATORWhen experiencing any power supply abnormality, the indicator will alert gamers by flashing light.ANTI-SAG BRACKETThe new anti-sag bracket is tailored to each graphics card. It provides the optimized reinforcement and better overall visual appearance.ULTRA DURABLEUltra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.FRIENDLY PCB DESIGNFully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.4-YEAR WARRANTYWe want you to experience the best service you have ever had. This is why, on top of our standard 3-year warranty, we would like to offer you an additional 1 year of protection to your graphics card free of charge. You can enjoy a 4-year warranty by registering on the website within 30 days of purchase.GIGABYTE CONTROL CENTERGIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
LongProductName - RTX 4090 PCIe x16, 24GB GDDR6, 3xDP1.4, 1xHDMI 2.1, AERO OC
LongSummaryDescription - Gigabyte AERO GeForce RTX 4090 OC 24G. Graphics processor family: NVIDIA, Graphics processor: GeForce RTX 4090. Discrete graphics card memory: 24 GB, Graphics card memory type: GDDR6X, Memory bus: 384 bit, Memory clock speed: 2100 MHz. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12.0, OpenGL version: 4.6. Interface type: PCI Express 4.0. Cooling type: Active, Number of fans: 3 fan(s)
Manufacturer - GigaByte
Manufacturer - Gigabyte
Manufacturer Code - GV-N4090AERO OC-24GD
Manufacturer Name - Gigabyte
Manufacturer_code - GV-N4090AERO OC-24GD
Max resolution - 7680x4320
Memory - Discrete graphics card memory - 24 GB
Memory - Graphics card memory type - GDDR6X
Memory - Memory bus - 384 bit
Memory - Memory clock speed - 2100 MHz
Memory > Discrete graphics adapter memory - 24 GB
Memory > Graphics adapter memory type - GDDR6X
Memory > Memory clock speed - 21000 MHz
Memory bus - 384 bit
Memory CLK - 21 Gbps
Model - GV-N4090AERO OC-24GD
MPN - GV-N4090AERO OC-24GD
name - GIGABYTE GeForce RTX 4090 Aero OC 24G, 24576 MB GDDR6X
Name - GIGABYTE GeForce RTX 4090 AERO OC 24G, graphics card (DLSS 3, 3x DisplayPort, 1x HDMI 2.1)
Name - Gigabyte | GV-N4090AERO OC-24GD 1.0 | NVIDIA | 24 GB | GeForce RTX 4090 | GDDR6X | HDMI ports quantity 1 | PCI-E 4.0 | Memory clock speed 21000 MHz
Name - RTX 4090 24GB Gigabyte Aero OC GDDR6X 3Fan
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 475.00 mm
Package features > Gross depth master carton - 725 mm
Package features > Gross height (mm) - 115.00 mm
Package features > Gross height master carton - 310 mm
Package features > Gross width (mm) - 279.00 mm
Package features > Gross width master carton - 465 mm
Package features > Net weight master carton - 16 kg
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 113 pc(s)
Package features > Paper/Pasteboard - 400.00 g
Package features > Plastic (No PET) - 100.00 g
Package features > Tare weight (kg) - 0.50 kg
Package features > Tare weight master carton - 1.777 kg
Package features > Volume (m3) - 0.02 m³
Package features > WEEE tax - No
Packaging data - Package type - Box
Performance - DirectX version - 12.0
Performance - Dual Link DVI - No
Performance - HDCP - Yes
Performance - OpenGL version - 4.6
Performance - TV tuner integrated - No
Ports & interfaces - DisplayPorts quantity - 3
Ports & interfaces - DisplayPort version - 1.4
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - Interface type - PCI Express 4.0
Ports & interfaces > DisplayPorts quantity - 3
Ports & interfaces > HDMI ports quantity - 1
Ports & interfaces > Interface type - PCI-E 4.0
Power - Minimum system power supply - 1000 W
Power - Supplementary power connectors - 1x 16-pin
Power connectors - 16 pin
Processor - CUDA - Yes
Processor - CUDA cores - 16384
Processor - Graphics processor - GeForce RTX 4090
Processor - Graphics processor family - NVIDIA
Processor - Maximum displays per videocard - 4
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Parallel processing technology support - Not supported
Processor > Graphics processor - GeForce RTX 4090
Processor > Graphics processor family - NVIDIA
Producer product name - GV-N4090AERO OC-24GD 1.0
ProductName - GeForce RTX 4090 AERO OC 24G
Shipping Box Depth Shipping/Package Box Dimensions - 47 cm
Shipping Box Height Shipping/Package Box Dimensions - 12 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 2.931 kg
Shipping Box Width Shipping/Package Box Dimensions - 28 cm
Short description - GIGA VGA 24GB RTX4090 AERO OC-24GD 3xDP/3xHDMI GeForce RTX 4090 AERO OC-24GD
ShortSummaryDescription - Gigabyte AERO GeForce RTX 4090 OC 24G, GeForce RTX 4090, 24 GB, GDDR6X, 384 bit, 7680 x 4320 pixels, PCI Express 4.0
Technical details > Gross weight - 2.50 kg
Technical details > Net weight - 2.00 kg
Technical details > Producer - Gigabyte
Title - Gigabyte AERO GeForce RTX 4090 OC 24G NVIDIA 24 GB GDDR6X
Unit Box Height - 0.12
Unit Box Length - 0.47
Unit Box Width - 0.28
Unit Brutto Volume - 0.01579 cubm
Unit Gross Weight - 2.93 kg
Unit Net Weight - 2.4 kg
URL - https://www.gigabyte.com/Graphics-Card/GV-N4090AERO-OC-24GD#kf
Vendor Homepage - www.gigabyte.com/Graphics-Card/GV-N4090AERO-OC-24GD/sp#sp
Warranty - 36
Warranty - 36 month(s)
Warranty - 36 months
WarrantyInfo - 4 Years Warranty (Online registration required)
Weight - 2.98
Weight - 3,00
Weight & dimensions - Depth - 342 mm
Weight & dimensions - Height - 75 mm
Weight & dimensions - Width - 150 mm
GeForce -tunnus osoittaa, että tämä näytönohjain on riittävän tehokas, jotta se on yhteensopiva uusimpien VR-laitteiden (Virtual Reality), kuten Oculus Riftin, HTC Viven (SteamVR) jne. kanssa.
