Gigabyte GeForce RTX 4070 Ti SUPER, 16GB GDDR6X, GAMING OC (DLSS 3)

Accessories included - A quick guide Warranty registration Bracket to prevent sagging Anti-sag bracket installation instructions One 16-pin power supply for two 8-pin ones
Brand - GIGABYTE
BrandPartCode - GV-N407TSGAMING OC-16GD
Card's length - > 280 mm
Category - Datortehnika :: Datoru komponentes :: Videokartes (VGA)
Category - Graphics Cards
category - PC Components|Graphics Cards|NVIDIA|GeForce RTX 4070 Ti
Category - Root/Electronics/PC parts/Graphic cards
Category 1 - Grafikkarten
Category 2 - NVidia PCI-Express Grafikkarten
Category Code - VGP
Category_1 - Graphics Cards
Category_2 - Graphics Cards PCIe - Nvidia
Chipset - GeForce RTX 4070 Ti SUPER
Chipset - NVIDIA GeForce RTX 4070 Ti SUPER
Chipset manufacturer - NVIDIA
code - GV-N407TSGAMING OC-16GD
Code - GV-N407TSGAMING OC-16GD 1.0
Cooling - Active
CUDA Cores - 8448
Desc - Mikroshēmu tips: Nvidia GeForce RTX 4070 Ti Super, Takts frekvence: 2655 MHz, Atmiņas apjoms: 16 GB, Atmiņas veids: GDDR6X, Biti: 256 Bit, Takts frekvence atmiņai: 21000 MHz, Interfeisa tips: PCI-Express 4.0, DVI: Nav, VGA (D-Sub): Nav, Display Port: 3, HDMI: 1, Garantija: 2 gadi
Description - GeForce RTX™ 4070 Ti SUPER GAMING OC 16G KEY FEATURE - Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace arch, and full ray tracing - 4th Generation Tensor Cores: Up to 4X performance with DLSS 3 vs. brute-force rendering - 3rd Generation RT Cores: Up to 2X ray tracing performance - Powered by GeForce RTX™ 4070 Ti SUPER - Integrated with 16GB GDDR6X 256bit memory interface - WINDFORCE Cooling System - RGB Fusion - Dual BIOS - Protection metal back plate - Anti-sag bracket
Description - Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace Arc and full ray tracing 4th Gen Tensor Cores: Up to 4x faster performance with DLSS 3 rendering compared to brute-force rendering 3rd Gen RT Cores: Up to 2X ray tracing performance Powered by the GeForce RTX 4070 Ti SUPER card Integrated with 16GB GDDR6X 256bit memory interface WINDFORCE cooling system RGB fusion Dual BIOS Metal back plate for protection Bracket to prevent sagging 4-year warranty (online registration required)
Design - Cooling technology - GIGABYTE WINDFORCE 3X
Design - Cooling type - Active
Design - Form factor - Full-Height/Full-Length (FH/FL)
Design - Number of fans - 3 fan(s)
Design - Product colour - Black
dimensionalWeight - 1713
dimension depth - 100 mm
dimension height - 400 mm
Dimensions - 300 x 130 x 57.6 mm
Dimensions - 300x130x57.6mm
dimension weight - 1883 g
dimension width - 260 mm
DisplayPort Input/Output connectors - 3
EAN - 4719331354107
ean - 4719331354107
Eans - 4719331354107
EAN_code - 4719331354107
Full Description Line - NVIDIA GeForce RTX 4070 Ti SUPER|Graphics memory size 16 GB|GDDR6X|256 bit|PCIE 4.0 16x|Memory CLK 256 Gbps|GPU clock 2655 MHz|7680x4320|1xHDMI|3xDisplayPort
GPU clock - 2655 MHz
Graphic card features - Gaming/Overclock Edition
Graphics card connector - PCI-E ver. 4.0
Graphics connector - PCIE 4.0 16x
Graphics memory size - 16 GB
Graphics memory type - GDDR6X
Gross Weight Kg - 2,02
GTIN - 4719331354107
guarantee - 36
guarantee_type - normal
HDMI Input/Output connectors - 1
ImageUrl - https://www.balticdata.lv/Gfx/ProductImages/Info/Product_114194_1.jpg
LargeDescHTML -
LongDesc - WINDFORCECOOLING SYSTEMThe WINDFORCE cooling system features three 90mm unique blade fans, alternate spinning, 8 composite copper heat pipes, a copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipationWINDFORCECOOLING SYSTEMThe WINDFORCE cooling system features three 90mm unique blade fans, alternate spinning, 8 composite copper heat pipes, a copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipationWINDFORCECOOLING SYSTEMThe WINDFORCE cooling system features three 90mm unique blade fans, alternate spinning, 8 composite copper heat pipes, a copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipationALTERNATE SPINNINGReduce the turbulence of adjacent fans and increase airflow pressure.WINDFORCECOOLING SYSTEMThe WINDFORCE cooling system features three 90mm unique blade fans, alternate spinning, 8 composite copper heat pipes, a copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation3D ACTIVE FANThe 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.UNIQUE BLADE FANThe airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.GRAPHENE NANO LUBRICANTGraphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.LARGE COPPER PLATE & HEAT-PIPEThe large copper plate directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.LARGE COPPER PLATE & HEAT-PIPEThe large copper plate directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.SCREEN COOLINGExtended heatsink allows air to pass through, providing better heat dissipation.RGB FUSIONThe legendary three-ring lighting provides excellent visual enjoyment. You can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER .ULTRA DURABLEUltra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.FRIENDLY PCB DESIGNFully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.4-YEAR WARRANTYWe want you to experience the best service you have ever had. This is why, on top of our standard 3-year warranty, we would like to offer you an additional 1 year of protection to your graphics card free of charge. You can enjoy a 4-year warranty by registering on the website within 30 days of purchase.Power Through The GameGIGABYTE offers the best power supply solutions for your graphics cards. You can choose either the AORUS series or the UD series to power your graphics card.GIGABYTE CONTROL CENTERGIGABYTE CONTROL CENTER is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
LongProductName - NVIDIA GeForce RTX 4070 Ti SUPER, 16GB GDDR6X, 256 bit, 21000MHz, PCI Express 4.0, 1 x HDMI (2.1a), 3 x DP (1.4a), CUDA, DirectX 12 Ultimate, OpenGL 4.6
LongSummaryDescription - GIGABYTE GAMING GeForce RTX 4070 Ti SUPER OC 16G. Graphics processor family: NVIDIA, Graphics processor: GeForce RTX 4070 Ti SUPER, Processor frequency: 2610 MHz. Discrete graphics card memory: 16 GB, Graphics card memory type: GDDR6X, Memory bus: 256 bit, Memory clock speed: 21000 MHz. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12 Ultimate, OpenGL version: 4.6. Interface type: PCI Express 4.0. Cooling type: Active, Number of fans: 3 fan(s)
Manufacturer - GigaByte
Manufacturer - Gigabyte
Manufacturer Code - GV-N407TSGAMING OC-16GD
Manufacturer Name - Gigabyte
Manufacturer_code - GV-N407TSGAMING OC-16GD
Max resolution - 7680x4320
Memory - Discrete graphics card memory - 16 GB
Memory - Graphics card memory type - GDDR6X
Memory - Memory bandwidth (max) - 21 GB/s
Memory - Memory bus - 256 bit
Memory - Memory clock speed - 21000 MHz
Memory > Discrete graphics adapter memory - 16 GB
Memory > Graphics adapter memory type - GDDR6X
Memory > Memory clock speed - 2655 MHz
Memory bus - 256 bit
Memory bus - 256-bit
Memory CLK - 256 Gbps
Memory frequency - 21 Gbps
Memory type - DDR6X
Model - GeForce RTX 4070 Ti SUPER GAMING OC 16G
Model - GV-N407TSGAMING OC-16GD
MPN - GV-N407TSGAMING OC-16GD
Name - GigaByte GeForce RTX 4070 Ti SUPER GAMING OC 16G (DLSS 3, 3x DisplayPort, 1x HDMI 2.1a)
name - GIGABYTE GeForce RTX 4070 Ti Super Gaming OC 16G, 16384 MB GDDR6X
Name - Gigabyte GeForce RTX 4070 Ti SUPER GAMING OC 16GB DLSS 3
Name - Gigabyte | GV-N407TSGAMING OC-16GD 1.0 | NVIDIA | 16 GB | GeForce RTX 4070 Ti SUPER | GDDR6X | HDMI ports quantity 1 | PCI-E 4.0 | Memory clock speed 2655 MHz
name - Graphics card RTX 4070 Ti SUPER GAMING OC 16G GDDR6X 256bit
Name - RTX 4070 Ti Super 16GB Gigabyte Gaming OC GDDR6X 3Fan
Name - Videokarte Gigabyte GeForce RTX 4070 Ti SUPER 16GB GAMING OC (DLSS 3)
Other features - Core clock speed TBD CUDA Cores TBD Maximum digital resolution 7680x4320 Multi-monitor 4 ATX PCB size Recommended PSU power supply: 750W Power Connectors 16 pin *1
Other information -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 475.00 mm
Package features > Gross height (mm) - 115.00 mm
Package features > Gross width (mm) - 279.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 57 pc(s)
Package features > Paper/Pasteboard - 600.00 g
Package features > Plastic (No PET) - 200.00 g
Package features > Tare weight (kg) - 0.80 kg
Package features > Volume (m3) - 0.02 m³
Package features > WEEE tax - No
Packaging data - Package depth - 398 mm
Packaging data - Package height - 85 mm
Packaging data - Package type - Box
Packaging data - Package weight - 2.02 kg
Packaging data - Package width - 230 mm
Performance - DirectX version - 12 Ultimate
Performance - Dual Link DVI - No
Performance - OpenGL version - 4.6
Performance - TV tuner integrated - No
Ports & interfaces - DisplayPorts quantity - 3
Ports & interfaces - DisplayPort version - 1.4a
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1a
Ports & interfaces - Interface type - PCI Express 4.0
Ports & interfaces > DisplayPorts quantity - 3
Ports & interfaces > HDMI ports quantity - 1
Ports & interfaces > Interface type - PCI-E 4.0
Power - Minimum system power supply - 750 W
Power - Supplementary power connectors - 1x 16-pin
Power connectors - 16 pin
Power consumption - 750 Watts
Processor - CUDA - Yes
Processor - Graphics processor - GeForce RTX 4070 Ti SUPER
Processor - Graphics processor family - NVIDIA
Processor - Maximum displays per videocard - 4
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Parallel processing technology support - Not supported
Processor - Processor frequency - 2610 MHz
Processor > Graphics processor - GeForce RTX 4070 Ti SUPER
Processor > Graphics processor family - NVIDIA
producer - Gigabyte
Producer - Gigabyte
producerCode - GV-N407TSGAMING OC-16GD
ProducerCode - GV-N407TSGAMING OC-16GD
Producer product name - GV-N407TSGAMING OC-16GD 1.0
ProductName - GeForce RTX 4070 Ti SUPER GAMING OC 16G
productName - GIGABYTE GAMING GeForce RTX 4070 Ti SUPER OC 16G NVIDIA 16 GB GDDR6X
productSize - Normal
Shipping Box Depth Shipping/Package Box Dimensions - 49 cm
Shipping Box Height Shipping/Package Box Dimensions - 48 cm
Shipping box quantity - 10
Shipping Box Weight Shipping/Package Box Dimensions - 20.1 kg
Shipping Box Width Shipping/Package Box Dimensions - 43.5 cm
ShortDescription - Chipset NVIDIA RTX 4070 Ti SUPER | 16GB
Short description - GIGA VGA 16GB RTX4070Ti SUPER GAMING OC 16G 3xDP/HDMI GeForce RTX 4070 Ti SUPER GAMING OC 16G
ShortSummaryDescription - GIGABYTE GAMING GeForce RTX 4070 Ti SUPER OC 16G, GeForce RTX 4070 Ti SUPER, 16 GB, GDDR6X, 256 bit, 7680 x 4320 pixels, PCI Express 4.0
sizeX - 405
sizeY - 90
sizeZ - 235
Supported standards - DirectX 12 Ultimate
Supported standards - OpenGL 4.6
Technical details > Gross weight - 2.84 kg
Technical details > Net weight - 2.04 kg
Technical details > Producer - Gigabyte
Technical_details - The GIGABYTE GeForce RTX 4070 Ti SUPER GAMING OC 16G is a high-end graphics card with the GeForce RTX 4070 Ti SUPER GPU from NVIDIA. The powerful GeForce RTX 40 graphics card series is based on the NVIDIA Ada architecture and offers new levels of gaming realism, speed and performance efficiency, RTX IO and realistic VR experiences. Other features include Real-Time Ray Tracing, NVIDIA Ansel, with extensive tools for creating screenshots in games as well as NVIDIA G-SYNC, G-SYNC HDR, DirectX 12 Ultimate, NVIDIA DLSS 3.5, PCI Express Gen 4, NVIDIA FreeStyle, NVIDIA ShadowPlay , NVIDIA Highlights, NVENC Gen 8, AV1 Encoder, Vulkan RT API and OpenGL 4.6. The GPU installed on the GIGABYTE GeForce RTX 4070 Ti SUPER GAMING OC 16G has 8448 CUDA cores. The 16 GB GDDR6X memory has a 256-bit memory controller. Item no.: 100034382 Graphics card type EAN 4719331354107 Manufacturer no. GV-N407TSGAMING OC-16GD Slot PCIe x16 version 4.0 occupied slots 3 GPU name NVIDIA GeForce RTX 4070 Ti SUPER with heat pipe Yes Memory capacity 16 GB (GDDR6X) Connections 1x HDMI version 2.1a, 3x Displayport version 1.4a Power supply Average consumption 285 W Cooling Cooling with fan RGB Standard RGB Fusion Special features VR Ready Yes Feature RTX IO, NVIDIA DLSS 3.5, PCI Express Gen 4, NVIDIA GeForce Experience, NVIDIA Ansel, NVIDIA FreeStyle, NVIDIA ShadowPlay, NVIDIA Highlights, NVIDIA G-SYNC, Game Ready Driver, NVIDIA Studio Driver, NVIDIA GPU Boost, NVENC Gen 8, AV1 Encoder, Vulkan RT API More information Maximum digital resolution: 7680 x 4320 Note For the power supply, a power supply with a native 16-pin connector or a power supply with 2x 8-pin PCIe for the included adapter is required Accessories available: power adapter, graphics card holder Dimensions Width: 130mm x Height: 57.6mm x Depth/Length: 300mm
Title - GIGABYTE GAMING GeForce RTX 4070 Ti SUPER OC 16G NVIDIA 16 GB GDDR6X
Unit Box Height - 0.235
Unit Box Length - 0.405
Unit Box Width - 0.09
Unit Brutto Volume - 0.01023 cubm
Unit Gross Weight - 2.01 kg
Unit Net Weight - 1 kg
URL - https://www.gigabyte.com/Graphics-Card/GV-N407TSGAMING-OC-16GD#kf
Vendor Homepage - www.gigabyte.com/Graphics-Card/GV-N407TSGAMING-OC-16GD#kf
vendpn - GV-N407TSGAMING OC-16GD
Version - Box
Video ports - 1 x HDMI
Video ports - 3 x DisplayPort
VRAM memory size - 16 GB
Warranty - 36
Warranty - 36 month(s)
Warranty - 36 months
WarrantyInfo - 3+1 Year (Registration required within 30 days)
warrantyLength - 36
warrantyType - G
Weight - 1,87
Weight - 1.82
weight - 1865
Weight & dimensions - Depth - 57.6 mm
Weight & dimensions - Depth - 300 mm
Weight & dimensions - Height - 57.6 mm
Weight & dimensions - Height - 130 mm
Weight & dimensions - Width - 130 mm
