Brand - GIGABYTE
BrandPartCode - GV-N4070GAMING OCV2-12GD
Card's length - > 280 mm
Category - Graphics Cards
category - PC Components|Graphics Cards|NVIDIA|GeForce RTX 4070
Category Code - VGP
Category_1 - Graphics Cards
Category_2 - Graphics Cards PCIe - Nvidia
Chipset - NVIDIA GeForce RTX 4070
code - GV-N4070GAMING OCV2-12GD
Cooling system - Dual Slot Fansink
CUDA Cores - 5888
Description - Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace arch, and full ray tracing 4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering 3rd Generation RT Cores: Up to 2X ray tracing performance Powered by GeForce RTX™ 4070 Integrated with 12GB GDDR6X 192bit memory interface WINDFORCE cooling system RGB Fusion Dual BIOS Protection metal back plate
Design - Bracket height - Full-Height (FH)
Design - Cooling technology - GIGABYTE WINDFORCE 3X
Design - Cooling type - Active
Design - Fan diameter - 9 cm
Design - Form factor - Full-Height/Full-Length (FH/FL)
Design - Illumination - Yes
Design - Illumination colour - Multi
Design - Number of fans - 3 fan(s)
Design - Product colour - Black
DisplayPort Input/Output connectors - 3
ean - 4719331314873
EAN_code - 4719331314873
Full Description Line - NVIDIA GeForce RTX 4070|Graphics memory size 12 GB|GDDR6X|192 bit|PCIE 4.0 16x|Memory CLK 21 Gbps|GPU boost clock 2565 MHz|7680x4320|Cooling Dual Slot Fansink|1xHDMI|3xDisplayPort
GPU boost clock - 2565 MHz
Graphic card features - Gaming
Graphics connector - PCIE 4.0 16x
Graphics memory size - 12 GB
Graphics memory type - GDDR6X
GTIN - 4719331314873
HDMI Input/Output connectors - 1
LongDesc - WINDFORCE COOLING SYSTEMThe WINDFORCE cooling system features three 90mm unique blade fans, alternate spinning, 4 composite copper heat pipes directly touch the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.ALTERNATE SPINNINGReduce the turbulence of adjacent fans and increase airflow pressure.3D ACTIVE FANThe 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.UNIQUE BLADE FANThe airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.GRAPHENE NANO LUBRICANTGraphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.HEAT PIPES DIRECT TOUCHThe shape of the pure copper heat pipe maximizes the direct contact area with the GPU. The heat pipe also covers the VRAM through a large metal plate contact to ensure proper cooling.SCREEN COOLINGExtended heatsink allows air to pass through, providing better heat dissipation.RGB FUSIONThe legendary three-ring lighting provides excellent visual enjoyment. You can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.PROTECTION METAL BACK PLATEThe metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.DUAL BIOSThe factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience.POWER INDICATORWhen experiencing any power supply abnormality, the indicator will alert gamers by flashing light.BUILT STRONGULTRA DURABLEUltra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.FRIENDLY PCB DESIGNFully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.GIGABYTE CONTROL CENTERGIGABYTE CONTROL CENTER is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
LongProductName - 12 GB, GDDR6X, 192-bit, PCI-E 4.0, 2565 MHz core clock, HDMI, 3x DisplayPort, 1x 8-pin, RGB
LongSummaryDescription - GIGABYTE GAMING GeForce RTX 4070 OC V2. Graphics processor family: NVIDIA, Graphics processor: GeForce RTX 4070, Processor frequency: 2565 MHz. Discrete graphics card memory: 12 GB, Graphics card memory type: GDDR6X, Memory bus: 192 bit. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12 Ultimate, OpenGL version: 4.6. Interface type: PCI Express 4.0. Cooling type: Active, Number of fans: 3 fan(s), Illumination colour: Multi
Manufacturer - GigaByte
Manufacturer_code - GV-N4070GAMING OCV2-12GD
Max resolution - 7680x4320
Memory - Data transfer rate - 21 Gbit/s
Memory - Discrete graphics card memory - 12 GB
Memory - Graphics card memory type - GDDR6X
Memory - Memory bus - 192 bit
Memory - Number of pipelines - 4
Memory bus - 192 bit
Memory CLK - 21 Gbps
Model - GeForce RTX 4070 GAMING OC V2 12G
name - GIGABYTE GeForce RTX 4070 Gaming OC V2 12G, 12288 MB GDDR6X
Name - GIGABYTE GeForce RTX 4070 GAMING OC V2 12G, graphics card (DLSS 3, 3x DisplayPort, 1x HDMI 2.1)
Packaging content - User guide - Yes
Packaging data - Package type - Box
Performance - DirectX version - 12 Ultimate
Performance - NVIDIA 3D Vision - No
Performance - NVIDIA G-SYNC - Yes
Performance - OpenGL version - 4.6
Performance - TV tuner integrated - No
Ports & interfaces - DisplayPorts quantity - 3
Ports & interfaces - DisplayPort version - 1.4a
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1a
Ports & interfaces - Interface type - PCI Express 4.0
Power - Minimum system power supply - 650 W
Power - Supplementary power connectors - 1x 8-pin
Power connectors - 8 pin
Processor - CUDA - Yes
Processor - CUDA cores - 5888
Processor - Graphics processor - GeForce RTX 4070
Processor - Graphics processor family - NVIDIA
Processor - Maximum displays per videocard - 4
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Parallel processing technology support - Not supported
Processor - Processor frequency - 2565 MHz
ProductName - GeForce RTX 4070 OC V2
Shipping Box Depth Shipping/Package Box Dimensions - 41 cm
Shipping Box Height Shipping/Package Box Dimensions - 23 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 1.81 kg
Shipping Box Width Shipping/Package Box Dimensions - 9 cm
ShortSummaryDescription - GIGABYTE GAMING GeForce RTX 4070 OC V2, GeForce RTX 4070, 12 GB, GDDR6X, 192 bit, 7680 x 4320 pixels, PCI Express 4.0
System requirements - Windows operating systems supported - Windows 10 x64, Windows 11 x64
Title - GIGABYTE GAMING GeForce RTX 4070 OC V2 NVIDIA 12 GB GDDR6X
Unit Box Height - 0.23
Unit Box Length - 0.41
Unit Box Width - 0.09
Unit Brutto Volume - 0.008487 cubm
Unit Gross Weight - 1.81 kg
Unit Net Weight - 1.45 kg
URL - https://www.gigabyte.com/Graphics-Card/GV-N4070GAMING-OCV2-12GD
Vendor Homepage - www.gigabyte.com/Graphics-Card/GV-N4070GAMING-OCV2-12GD#kf
Warranty - 36 months
WarrantyInfo - 4 years
Weight - 1,50
Weight & dimensions - Depth - 50.2 mm
Weight & dimensions - Height - 130 mm
Weight & dimensions - Length - 300 mm
