JVC KWM-27DBT

Accessories included -
Audio formats - AAC
Audio formats - FLAC
Audio formats - MP3
Audio formats - WAV
Audio formats - WMA
Bands - AM
Bands - DAB+
Bands - FM (UKF)
CD player - No
Color - Black
Connectors - 1 x USB
Connectors - 3 x Audio Line-out (Back)
Connectors - 3 x Audio Line-out (Front)
Connectors - 3 x Audio Line-out (Subwoofer)
Connectors - AUX
Connectors - ISO connector
Description - KWM-27DBT car radio JVC's KW-M27DBT digital media receiver provides DAB / DAB + reception with Bluetooth technology for hands-free calling and wireless music streaming. With Android screen duplication via USB, apps such as Waze Navigation and Google Maps can be displayed and controlled via the 6.8-inch touchscreen. An optional reversing camera can be connected for reverse parking. This unit also supports music playback from an iPhone/iPod. Note: there is no CD mechanism on this model, however, allowing us to reduce the depth of the product to 75mm, which will fit into vehicles with less dashboard audio space than traditional products. USB Mirroring for Android Seamlessly display your Android phone on the JVC screen via USB. Touch control is operated from both the screen and your smartphone. Bluetooth wireless technology 2 Full-time phone connection: you can connect two phones full-time via Bluetooth, with secure and simple pairing. Calls to any phone can be answered by pressing a key on the head unit. Bluetooth 1.6 hands-free profile: HPF 1.6 Wideband Speech is supported, so you can now enjoy the convenience of hands-free telephoning, as well as higher voice quality and improved noise reduction. Automatic Bluetooth iPhone / Android pairing: simply connect your iPhone or Android device* via USB and the automatic Bluetooth pairing function will kick in. Don't worry about the complicated manual procedure. (* JVC Music Play app required). DAB+ tuner DAB (Digital Audio Broadcasting) provides crystal-clear sound from your favourite FM stations, as well as a wide range of digital-only stations, from news and talk to classical music and rock. Typically, DAB+ is delayed by a few seconds compared to FM broadcasts. Enjoy both better quality and richer content with DAB+.
Diagonal screen - 6,8''
Dimension - 2 DIN
dimensionalWeight - 1366
dimension depth - 160 mm
dimension height - 180 mm
Dimensions - 178 x 100 x 75 mm
dimension weight - 1720 g
dimension width - 230 mm
Display - Backlight colour - Blue
Display - Built-in display - Yes
Display - Display diagonal - 17.3 cm (6.8")
Display - Display resolution - 800 x 480 pixels
Display - Rear-view camera ready - Yes
Display - Touchscreen - Yes
ean - 4975769025242
FM tuner - Yes
GPS receiver - No
guarantee - 24
guarantee_type - external
Memory card - Not relevant
Memory card reader - No
Memory standard - Not applicable
Multimedia - Audio formats supported - AAC
Multimedia - Audio formats supported - FLAC
Multimedia - Audio formats supported - MP3
Multimedia - Audio formats supported - SBC
Multimedia - Audio formats supported - WAV
Multimedia - Audio formats supported - WMA
Multimedia - MP3 playback - Yes
Multimedia - USB direct playback - Yes
Multimedia - Video formats supported - AVI
Multimedia - Video formats supported - H.264
Multimedia - Video formats supported - MKV
Multimedia - Video formats supported - MPEG1
Multimedia - Video formats supported - MPEG2
Multimedia - Video formats supported - MPEG4
name - Radio car KWM-27DBT
Other display parameters - Touch control Panel type: capacitive with printing Pixel count: 1,152,000 (800 x 480 x RGB) Key-pad backlight colour: blue Resistor Configurable graphical user interface Multilingual display
Other features -
Output power - 4 x 45 W
Performance - Analog signal format system - NTSC
Performance - Analog signal format system - PAL
Performance - Bass adjustment - Yes
Performance - DIN size - 2 DIN
Performance - Equalizer - Yes
Performance - Equalizer bands quantity - 13
Performance - Product colour - Black
Performance - Steering mounting remote control capability - Yes
Performance - Total output power - 45W x 4
Ports & interfaces - AV input - Yes
Ports & interfaces - Bluetooth - Yes
Ports & interfaces - Bluetooth functions - Audiostreaming, Handsfree calling
Ports & interfaces - Bluetooth profiles - A2DP, AVRCP, HFP, PBAP
Ports & interfaces - Bluetooth version - 4.2
Ports & interfaces - ISO connector - Yes
Ports & interfaces - Line outputs (RCA) - 3
Ports & interfaces - Smartphone/tablet remote support - Yes
Ports & interfaces - Subwoofer out - Yes
Ports & interfaces - USB port - Yes
Ports & interfaces - USB port position - Rear
Ports & interfaces - USB ports quantity - 1
Ports & interfaces - Video RCA outputs - 1
Presseting - 30
producer - JVC
producerCode - KWM-27DBT
productName - Media Station JVC KW-M27DBT (2 DIN) Bluetooth
productSize - Normal
Radio - AM band range - 531 - 1.611 kHz
Radio - FM band range - 87.5 - 108 MHz
Radio - Preset stations quantity - 30
Radio - Supported radio bands - AM
Radio - Supported radio bands - DAB+
Radio - Supported radio bands - FM
Radio - Supported radio bands - LW
Radio - Supported radio bands - MW
sizeX - 232
sizeY - 160
sizeZ - 184
Special functions - Voice dialing Remote control application Hands-free calling (HFP) (HFP1.6 wideband speech) Advanced Audio Distribution Profile (A2DP) Phonebook access profile (PBAP) Phonebook alphabet search Wired microphone included Mirroring for Android Wired mirroring: yes (via USB) Music playback on Android: yes (via Bluetooth(R)) Battery charging: yes (USB: max. 1 A) iPod/iPhone music playback: yes (via USB or Bluetooth(R)) iPod/iPhone mode (two-way control): yes (USB) Random/repeated playback: yes (USB) Battery charge: yes (USB: max. 1 A) 13-band graphic equaliser Pre-set equaliser: yes (7 presets + 3 users) Easy EQ setting High pass filter/low pass filter Time alignment
Supported CD formats - None
Supported DVD formats - None
System - NTSC
System - PAL
TV tuner - None
USB playback - Yes
vendpn - JVC KWM-27DBT
Video formats - AVI
Video formats - H.264/AVC
Video formats - MKV
Video formats - MPEG-2
Video formats - MPEG-4
warrantyLength - 24
warrantyType - F
weight - 1720
Weight & dimensions - Depth - 75 mm
Weight & dimensions - Height - 100 mm
Weight & dimensions - Weight - 1.3 kg
Weight & dimensions - Width - 178 mm
Wireless communication - Bluetooth
