ARTIKEL1 - 16-P 10/100TX INT PSU EU POWER
ARTIKEL2 - UNMANAGED SWITCH 990-005847-50 I
Brand - Allied Telesis
BrandPartCode - 990-005847-50
Category - Network Switches
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Switching capacity - 3.2 Gbit/s
Data transmission - Throughput - 2.38 Mpps
Design - Form factor - 1U
Design - LED indicators - Yes
Design - Product colour - Green, Grey
Design - Rack mounting - Yes
EANCode - 0767035211893
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 0767035211893
GTIN - 767035211893
HERSTELLER - ALLIED TELESIS
HSTNUMMER - AT-FS710/16-50
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Overview The FS710 Series switches provide silent operation, with easy set-up and simple connectivity for desktop and small to medium network environments.High performance Full auto-negotiating 10/100 ports allow FS710 switches to detect the speed and duplex modes of attached devices, and automatically configure for the best possible performance.Quality and reliability Allied Telesis is a world-wide leader in unmanaged Ethernet switches. Shipping more than 250,000 unmanaged switches every year, Allied Telesis offers proven reliability, and industry-recognized quality.Flexibility Available in 5, 8, 16 and 24-port models, the FS710 Series provide both internal and external power supply options. Wall, desk and rack-mounting options give users ultimate flexibility in selecting the model that meets their specific physical deployment requirements.Fanless for silent operation The FS710 Series are fanless and run silently, making them ideal for the desktop or workspace. Deploy in dusty industrial environments without affecting the expected lifetime.Simplified installation Auto-configuration of the FS710 Series minimizes user set-up. Auto-sensing ports enable seamless and simple connectivity between existing 10Mbps Ethernet and 100Mbps Fast Ethernet UTP devices, so installation takes just minutes. All ports support MDI/MDI-X simple connection to other hubs and switches. Environmentally friendly FS710 Series eco-friendly switches conform to the Allied Telesis commitment to environmentallyfriendly processes and products. They are designed to minimize power consumption through the use of a high-efficiency power supply and a low-power chipset. With low power consumption and a reduction in power outside regular work hours, as well as other powersaving features included as standard, the Allied Telesis FS710 Series truly lives up to its eco-friendly reputation. Not only does this help the planet by reducing the carbon footprint of each switch, it also lowers the Total Cost of Ownership (TCO) for the user. The device costs less to run, and features improved reliability
LongProductName - 16-port 10/100TX unmanaged switch with internal PSU f/ European power cord
LongSummaryDescription - Allied Telesis AT-FS710/16-50. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 8000 entries, Switching capacity: 3.2 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x. Power connector: DC-in jack. Rack mounting, Form factor: 1U
Management features - Switch type - Unmanaged
Network - 10G support - No
Network - Auto MDI/MDI-X - Yes
Network - Flow control support - Yes
Network - Networking standards - IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Operational conditions - Operating altitude - 0 - 2000 m
Operational conditions - Operating relative humidity (H-H) - 5 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -25 - 70 °C
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 16
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Fast Ethernet (10/100)
Ports & interfaces - Power connector - DC-in jack
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 5.4 W
ProductName - AT-FS710/16-50
ShortSummaryDescription - Allied Telesis AT-FS710/16-50, Unmanaged, Fast Ethernet (10/100), Rack mounting, 1U
Stck_Kart - 10
Stck_Pal - 10
Storno - Y
Title - Allied Telesis AT-FS710/16-50 Unmanaged Fast Ethernet (10/100) 1U Green, Grey
URL - https://www.alliedtelesis.com/products/fs71016e
WarrantyInfo -
Weight & dimensions - Depth - 124 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 870 g
Weight & dimensions - Width - 210 mm
