Zyxel GS1100-10HP, UNMANAGE POE 8X GIGABIT, 2X FIBER UPLINK, 130 WATT POE V3

Accessories included - Power Supply Power cable Wall mounting kit
Application - Home and small office
Auto MDI/MDI-X - Yes
Brand - Zyxel
BrandPartCode - GS1100-10HP-EU0102F
Broadcast storm control - Yes
Category - Network Switches
Category - Root/Electronics/Networks and communication/Switchers
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates - Compliance certificates - RoHS
Certification - C-Tick Class B
Certification - CE
Certification - FCC
Chassis type - Desktop
Colour of product - Black
Console port - No
Data transmission - Forwarding rate - 14.88 Mpps
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Packet buffer memory - 0.256 MB
Data transmission - Switching capacity - 20 Gbit/s
Description - Whisper quiet operation The fanless design of the GS1100 ensures quiet operation in small and quiet office environments. The GS1100-10HP PoE model features an external power supply that eliminates the need for an additional fan to cool the unit, making it ideal for quiet PoE applications. Energy Saving The GS1100 is equipped with energy-efficient Ethernet (IEEE 802. 3az) that automatically detects network traffic and dynamically adjusts power consumption. Zyxel's green features also adjust power consumption by detecting link status and cable length and reducing operating costs. PoE+ Support The GS1100-10HP supports PoE+ (IEEE 802. 3at), which provides up to 30 watts per port and provides fully automatic support for compatible IP phones, video surveillance cameras or wireless access points.
Description - ZYXEL GS1100-10HP, UNMANAGE POE 8X GIGABIT, 2X FIBER UPLINK, 130 WATT POE V3
Design - Country of origin - China
Design - LED indicators - Yes
Design - Product colour - Black
Design - Wall mountable - Yes
dimensionalWeight - 1085
dimension depth - 250 mm
dimension height - 65 mm
Dimensions - 250 x 104 x 27 mm
Dimensions W x D x H, mm - 250 x 104 x 27
dimension weight - 1800 g
dimension width - 300 mm
Drive device, buffer size, MB - 0.256
ean - 4718937621187
EAN - 4718937621187
Eans - 4718937621187
EAN_code - 4718937621187
Ethernet LAN (RJ-45) PoE ports quantity - 8
Fan - No
Forwarding mode - Store-and-forward
Forwarding rate - 14.88 Mpps
GTIN - 4718937621187
guarantee - 24
guarantee_type - external
Height - 65.000000
Jumbo frame size - 9000 KB
Jumbo Frames support - Yes
L2 features -
L3 features -
Length - 300.000000
Logistics data - Country of origin - China
Logistics data - Harmonized System (HS) code - 85176990
Logistics data - Master (outer) case gross weight - 13.7 kg
Logistics data - Master (outer) case height - 275 mm
Logistics data - Master (outer) case length - 558 mm
Logistics data - Master (outer) case width - 323 mm
Logistics data - Products per master (outer) case - 8 pc(s)
LongDesc - Affordable Solution for Gigabit Connections to the DesktopThe ZyXEL GS1100 Series is the best solution for instant Gigabit connectivity in office environments demanding silent operation and better energy efficiency. With power-saving functions, Gigabit Ethernet and a fanless design, the GS1100 Series provides plug-and-play simplicity for high-bandwidth network applications.Green networkingThe GS1100 Series not only offers Gigabit Ethernet connectivity for next-generation network applications, but also power-saving functions for better energy efficiency. Capable of dynamically adjusting power output according to traffic, active links and cable length, the GS1100 Series can reduce energy consumption for lowered operating costs.Traffic detection — Energy Efficient Ethernet (EEE) complianceThe IEEE 802.3az Energy Efficient Ethernet (EEE) feature automatically detects network traffic and adjusts power consumption dynamically, enabling the switch to reduce power consumption during low link utilization periods. The GS1100 Series comes with IEEE 802.3az on/off button to help reduce power consumption. This button allows users to keep the best performance without transmit impacted or to have green support of Energy Efficient Ethernet mode with a simple push of a button.Inactive link detectionThe inactive link detection function automatically reduces power usage when inactive links or devices are detected. The ZyXEL GS1100 Series can adjust power consumption according to link status and the number of active network devices.Cable length detectionThis green feature enables the switch to automatically detect the length of connected Ethernet cables and adjust power usage accordingly. The shorter the cable length, the less power it consumes.Fanless designThe complete GS1100 Series comes in a fanless design that ensures silent operation in small or quiet office environments. The GS1100-8HP and GS1100-10HP PoE models are specifically designed with an external power adapter that eliminates the need for an additional fan to cool down the device, making it perfect for quiet PoE deployments.Gigabit to the desktopThe ZyXEL GS1100 Series offers small offices 8/10/16/24-port Gigabit connectivity at the most competitive price. Additionally, the GS1100-24 and GS1100-10HP models are equipped with 2 extra SFP slots, supported dual rate (100 M and GbE speed) that enable fiber optic connections for long-distance deployments. With Gigabit network performance and high cost-effectiveness, the GS1100 Series is the ideal solution for bandwidth-intensive applications such as high-resolution photo transmission, video/ audio streaming and server farm connections.Freedom of installation via PoE (GS1100-8HP/10HP)The GS1100-8HP/10HP supports the IEEE 802.3at PoE Plus standard to ease the installation of network devices in challenging spaces such as ceilings or walls. The power supply of up to 30 watts per port allows the GS1100-8HP/10HP to power PoE-enabled WLAN APs, VoIP phones and IP surveillance cameras through CAT-5 cables without extra power adapters. This feature helps enterprises reduce installation time and cost when there are many such devices on the network. The GS1100-10HP has been designed with eight full PoE Plus ports with total PoE power budget of up to 130 Watts, which makes it an ideal connectivity solution for high-density powered device deployments. In addition, the extra two SFP links on GS1100-10HP also easily extend networks to remote locations such as branch offices and warehouses for small- and medium-size businesses.
LongProductName - 8-port GbE Unmanaged PoE Switch with GbE Uplink
LongSummaryDescription - Zyxel GS1100-10HP v2. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 8000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE.... DC input voltage: 54 V. Power connector: DC-in jack. Power over Ethernet (PoE). Wall mountable
MAC address table, entries - 8000
MAC address table size - 8000
Management, monitoring, configuration -
Management features - Switch type - Unmanaged
Manufacturer - Zyxel
Manufacturer - ZYXEL NETWORKS
ManufacturerPartNumber - GS1100-10HP-EU0102F
Manufacturer_code - GS1100-10HP-EU0102F
Maximum data transfer rate, Gbit/s - 1
Mean time between failures (MTBF) - 1000070 h
MPN - GS1100-10HP-EU0102F
Name - 8+2P Zyxel GS1100-10HPV2
name - GS1100-10HP-EU0102F 120W PoE 8xGigabit 2xFiber Uplilk Switch
Name - Zyxel GS1100-10HP-EU0102F
Name - Zyxel GS1100-10HP v2, switch
Network - 10G support - No
Network - Auto MDI/MDI-X - Yes
Network - Ethernet LAN data rates - 100,1000 Mbit/s
Network - Networking standards - IEEE 802.1p
Network - Networking standards - IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Network - Networking standards - IEEE 802.3
Network - Networking standards - IEEE 802.3ab
Network - Networking standards - IEEE 802.3af
Network - Networking standards - IEEE 802.3at
Network - Networking standards - IEEE 802.3az
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Network - Networking standards - IEEE 802.3z
Network architecture - GigabitEthernet
Networking features - Gigabit Ethernet
Networking standards - IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3x, IEEE 802.1p, IEEE 802.3at, IEEE 802.3af
Number of 10/100/1000 Mbps ports - 8
Number of PoE ports (PoE & PoE+) - 8
Number of SFP ports - 2
Operating temperature range (T-T), °C - 0 - 50 °C
Operational conditions - Heat dissipation - 89 BTU/h
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other functions -
Packaging data - Package depth - 304 mm
Packaging data - Package height - 67 mm
Packaging data - Package weight - 1.97 kg
Packaging data - Package width - 228 mm
Packet buffer - 256 KB
Packet transfer speed - 11.9 Mpps
Performance - Mean time between failures (MTBF) - 1000070 h
PeriodofWarranty -
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 8
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Power connector - DC-in jack
Ports & interfaces - SFP module slots quantity - 2
Ports quantity - 10
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - DC input voltage - 54 V
Power - Power consumption (max) - 156.1 W
Power - Power source - AC/DC
Power - Power supply included - Yes
Power consumption - 156.1 W
Power consumption, W - 90
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 8
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 130 W
Power over Ethernet (PoE) Support - Yes
Power supply - 100 - 240 V AC, 50/60 Hz
Power supply - External
producer - Zyxel
Producer - Zyxel
producerCode - GS1100-10HP-EU0102F
ProducerCode - GS1100-10HP-EU0102F
ProductName - GS1100-10HP v2
productName - Zyxel GS1100-10HP v2 Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
productSize - Normal
QoS -
Safety - LVD EN60950-1, BSMI CNS14336-1
Security -
SFP slots quantity - 2
ShortDescription -
ShortSummaryDescription - Zyxel GS1100-10HP v2, Unmanaged, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Wall mountable
sizeX - 310
sizeY - 70
sizeZ - 250
Storage temperature range (T-T), °C - -40 - 70 °C
Supported data transfer rates - 10/100/1000 Mbps
Supported protocols and standards - IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Ethernet IEEE 802.3ab 1000BASE-T Ethernet IEEE 802.3az EEE support IEEE 802.3x flow control IEEE 802.3z 1000BASE-X IEEE 802.1p CoS IEEE 802.3af PoE (GS1100-10HP) IEEE 802.3at PoE+ (GS1100-10HP)
Support for Jumbo frames - Yes
Sustainability - Sustainability certificates - RoHS
Sustainability - Sustainability compliance - Yes
Switch class - Unmanaged
Switching capacity, Gbit/s - 16
Switch type - Unmanaged
Technical details - Compliance certificates - RoHS
Throughput - 20 Gb/s
Title - Zyxel GS1100-10HP v2 Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
URL - https://www.zyxel.com/products_services/8-16-24-port-GbE-Unmanaged-Switch-GS1100-Series/photos
vendpn - GS1100-10HP-EU0102F
VLAN -
WarrantyInfo - Limited Lifetime
warrantyType - W
Weight - 0.73 kg
Weight - 1,70
Weight - 1.76
Weight - 1.700000
weight - 1800
Weight & dimensions - Depth - 104 mm
Weight & dimensions - Height - 27 mm
Weight & dimensions - Weight - 730 g
Weight & dimensions - Width - 250 mm
Weight, g - 730
Width - 250.000000
