Dahua PFS3110-8ET-96-V2 8PORT POE

Brand - Dahua Technology
BrandPartCode - DH-PFS3110-8ET-96-V2
Category - Network Switches
Category Code - SWI
Data transmission - Forwarding rate - 4.17 Mpps
Data transmission - MAC address table - 8000 entries
Data transmission - Packet buffer memory - 1 MB
Data transmission - Switching capacity - 7.6 Gbit/s
Description - > Eight-PIN Assignment PoE Power Supply > Intelligent PoE > Red port supports 90W IEEE802.3bt > PoE watchdog > 250 m long distance PoE transmission > Wide operating temperature: –30°C to +65°C (–22°F to +149°F) Communication Standard IEEE802.3; IEEE802.3u; IEEE802.3X; IEEE 802.3ab; IEEE 802.3z PoE Standard IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt PoE Power 96W
Design - Form factor - 10U
Design - Product colour - Black
Design - Rack mounting - No
Design - Stackable - No
Dimensions - 190 × 100 × 30mm
Forwarding rate - 2.678 Mpps
Full Description Line - PoE ports 8|PoE power budget 96 Watts|Switching capacity 3.6 Gbps|Forwarding rate 2.678 Mpps|Dimensions 190 × 100 × 30mm|Unit Net Weight 0.47 kg
GTIN - 6923172503862
LongDesc - System OverviewDH-PFS3110-8ET-96 is an unmanaged Hardened PoE Switch with 8 ×10/100Mbps PoE Ports. It provides 8 × 10/100 Mbps Ethernet ports ,1 × 1000M SFPand 1× 10/100/1000 Mbps uplink ports. The productis equipped with two types of transmission modes (Extend Mode On/Extend Mode Off). The red port supports the IEEE802.3bt and theHi-PoE standards. The maximum power consumption is 90W. It alsosupports PoE watchdog to avoid manually maintenance and devicerestart, which can realize the intelligent management and reduce thecost. FunctionsIntelligent PoEProvides control over power consumption and offers real-timemonitoring to ensure power supplies receive priority with importantports and to prevent malfunctions caused by changes in powerconsumption. Supports ultra wide power supplies and is able to adaptto IPC power fluctuations.BT 90WThe red ports support IEEE802.3af, IEEE802.3at, IEEE802.3bt and Hi-PoEstandards, with a maximum output power consumption rate of 90W perport. Suitable for powering high-power devices.PoE WatchdogAdopts the innovative PoE Watchdog. PoE Watchdog can be switchedon by dialing or turning on the WEB page switch. It enables the switchto automatically detect port status and restart failed ports to recoverconnection in case of IPC connection exception. This enables intelligentoperation and maintenance management in its truest sense, effectivelyreducing manual maintenance costs.Long Distance PoEBy dialing or enabling long-range transmission on the WEB interface,the transmission distance of a PoE port can be up to 250 m, meeting therequirements of wired transmission (bandwidth reduced to 10 Mbps).8-pin Assignment PoE Power SupplySupports 8-pin simultaneous power supply (1/2/4/5 positive, 3/6/7/8negative). Signal lines and idle lines supply power at the same time.Compatibility with IPC is enhanced. Cable loss is reduced. Loadingcapacity is increased.SceneThe device is applicable for use in different scenarios, including home,office, server farm, and small mall.
LongProductName - 10-Port Unmanaged Desktop Switch with 8 Port PoE
LongSummaryDescription - Dahua Technology PFS3110-8ET-96-V2. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 9. MAC address table: 8000 entries, Switching capacity: 7.6 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z. Power over Ethernet (PoE). Form factor: 10U
Management features - Switch type - Unmanaged
Model name - PFS3110-8ET-96-V2
Network - 10G support - No
Network - Networking standards - IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
PoE ports - 8
PoE power budget - 96 Watts
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 9
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Fast Ethernet (10/100)
Ports & interfaces - SFP module slots quantity - 1
Power - Input voltage - 53 V
Power - Power source - AC
Power - Power supply included - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 45 W
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 96 W
Primary port count - 8
ProductName - PFS3110-8ET-96-V2
Shipping Box Depth Shipping/Package Box Dimensions - 26.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 24.5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 1.334 kg
Shipping Box Width Shipping/Package Box Dimensions - 8 cm
ShortSummaryDescription - Dahua Technology PFS3110-8ET-96-V2, Unmanaged, Fast Ethernet (10/100), Power over Ethernet (PoE), 10U
Switching capacity - 3.6 Gbps
Title - Dahua Technology PFS3110-8ET-96-V2 Unmanaged Fast Ethernet (10/100) Power over Ethernet (PoE) 10U Black
Unit Box Height - 0.245
Unit Box Length - 0.265
Unit Box Width - 0.08
Unit Brutto Volume - 0.005194 cubm
Unit Gross Weight - 1.33 kg
Unit Net Weight - 0.47 kg
URL - https://www.dahuasecurity.com/products/productDetail/29217
Vendor Homepage - www.dahuasecurity.com/products/All-Products/Transmission/PoE-Switches/Hardened-PoE-Switch/PFS3110-8ET-96
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth - 100 mm
Weight & dimensions - Height - 42 mm
Weight & dimensions - Weight - 540 g
Weight & dimensions - Width - 150 mm
