Intellinet 561334, 48x1GE 4SPF

10/100/1000/2500 Mbps ports - None
Accessories included - 48-Port Managed Gigabit Ethernet Switch with 4 SFP Slots Power cable User manual 19" mounting brackets
Application - Medium and large companies
Brand - Intellinet
BrandPartCode - 561334
Category - Network Switches
Category - Root/Electronics/Networks and communication/Switchers
Certificates - FCC Class A, CE
Certificates - Certification - FCC A, CE
Chassis type - Rack
Console port - No
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Packet buffer memory - 1.5 MB
Data transmission - Packet forwarding rate (1 Gbps) - 1488000 pps
Data transmission - Packet forwarding rate (10 Mbps) - 14880 pps
Data transmission - Packet forwarding rate (100 Mbps) - 148800 pps
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 104 Gbit/s
Description - 48-port Gigabit RJ45 4x SFP managed switch
Design - Certification - FCC A, CE
Design - Housing material - Metal
Design - LED indicators - Activity
Design - LED indicators - Activity, Link, Power, Speed
Design - LED indicators - Link
Design - LED indicators - Power
Design - LED indicators - Speed
Design - Product colour - Black
Designation - CE+WEEE
dimensionalWeight - 23833
dimension depth - 390 mm
dimension height - 80 mm
Dimensions - 335 x 440 x 44 mm
dimension weight - 5500 g
dimension width - 600 mm
ean - 766623561334
Eans - 0766623561334
Environment requirements - Operating temperature: 0 - 40°C Operating humidity: 10% - 90% RH, non-condensing Storage temperature: -20 - 70°C
Fan - No
Forwarding mode - Store-and-forward
GTIN - 766623561334
GTIN - 0766623561334
guarantee - 36
guarantee_type - external
Jumbo frame size - 9 KB
L2 features -
L3 features -
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Intelligent and secure edge connectivity, ideal for small and medium enterprise or branch office networks and essential business applications. This 48 + 4 Layer 2 Gigabit Switch is a high-performance SNMP-managed device that provides users with 48 10/100/1000 Mbps Ethernet and 4 additional Gigabit SFP ports. The Web/SNMP management provides remote control capability for flexible network management and monitoring options. Whether managed through an in-band SNMP management station or an Internet Web browser, the Intellinet Network Solutions Gigabit switch (561334) facilitates network administration and problem diagnosis. Flexible Network Management The Intellinet Network Solutions 48-Port Web-Managed Gigabit Ethernet Switch is easy to use and manage, designed to increase business productivity by reliably supporting business applications. It features a Web-based GUI and supports SNMP, RMON and Telnet. The impressive list of features includes, but is not limited to, ACL management, sophisticated QoS-related settings, port mirroring, integrated IP-connectivity tools, logging, MAC filtering, RADIUS authentication, Port aggregation and detailed port rate configuration options. Eliminate Bottlenecks with 52 Gigabit Ports Equipped with 48 auto-sensing 10/100/1000 Mbps RJ45 Gigabit Ethernet ports, this switch offers plenty of performance for your computers, servers and other networking devices. in addition, four small, form-factor pluggable GBIC module slots (SFP) provide fibre connectivity for greater distances. These are not shared combo-ports, but true Gigabit ports, pushing the total available bandwidth up to 104 Gbps. Green Ethernet Technology More often than not, a network switch does not utilize all its ports at all times. Normally, when a computer, notebook, network printer or other network device is powered down, the switch continues to consume the same amount of power as if it were active. Now, thanks to energy-efficient IEEE 802.3az technology, the Intellinet Network Solutions 48-Port Managed Gigabit Switch detects link status to all connected devices and reduces the power usage of ports not in use. In addition, the Intellinet Network Solutions switch can adjust the level of power output based on the length of the network cable connected to a particular port. With the Intellinet Network Solutions 48-Port Web-Managed Gigabit Ethernet Switch you, will enjoy maximum network performance. But when things slow down, it automatically scales back power usage to conserve energy and save money.
LongProductName - 48-Port Gigabit Ethernet Web-Managed Switch with 4 SFP Ports, 48 x 10/100/1000 Mbps RJ45 Ports + 4 x SFP, IEEE 802.3az Energy Efficient Ethernet, SNMP, QoS, VLAN, ACL, 19 Rackmount" (Euro 2-pin plug)
LongSummaryDescription - Intellinet 48-Port Gigabit Ethernet Web-Managed Switch with 4 SFP Ports, 48 x 10/100/1000 Mbps RJ45 Ports + 4 x SFP, IEEE 802.3az Energy Efficient Ethernet, SNMP, QoS, VLAN, ACL, 19 Rackmount" (Euro 2-pin plug). Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48. Full duplex. MAC address table: 8000 entries, Switching capacity: 104 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE...
MAC address table size - 8000
Management, monitoring, configuration - Bandwidth management for all ports SNMP management and remote RMON monitoring
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2
Management features - Switch type - Managed
Management features - Web-based management - Yes
Memory buffer - 1500 KB
Multicast features - Multicast support - Yes
Name - Intellinet 561334 Switch 48p Gigabit SFP
name - Switch Gigabit 48-ports managed RJ45 4x SFP
Network - 10G support - No
Network - Auto-negotiation - Yes
Network - Auto MDI/MDI-X - Yes
Network - Broadcast storm control - Yes
Network - Cable types supported - Cat3
Network - Cable types supported - Cat3, Cat4, Cat5, Cat5e
Network - Cable types supported - Cat4
Network - Cable types supported - Cat5
Network - Cable types supported - Cat5e
Network - Copper ethernet cabling technology - 10BASE-T
Network - Copper ethernet cabling technology - 10BASE-T, 100BASE-TX, 1000BASE-T
Network - Copper ethernet cabling technology - 100BASE-TX
Network - Copper ethernet cabling technology - 1000BASE-T
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.1D
Network - Networking standards - IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Network - Networking standards - IEEE 802.1p
Network - Networking standards - IEEE 802.1Q
Network - Networking standards - IEEE 802.1s
Network - Networking standards - IEEE 802.3
Network - Networking standards - IEEE 802.3ab
Network - Networking standards - IEEE 802.3ad
Network - Networking standards - IEEE 802.3az
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Network - Port mirroring - Yes
Network - Rate limiting - Yes
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - Port-based VLAN
Network - Virtual LAN features - Tagged VLAN
Network - Virtual LAN features - Tagged VLAN, Port-based VLAN
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 48
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - None
Number of QSFP+ ports - None
Number of SFP+ ports - None
Number of SFP56 ports - None
Number of SFP ports - 4
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features -
Other functions -
Packaging content - Cables included - AC
Packaging content - Manual - Yes
Packaging content - Rack mount kit - Yes
Packaging data - Cables included - AC
Packaging data - Manual - Yes
Packaging data - Rack mount kit - Yes
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 48
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Fiber optic connector - MiniGBIC
Ports & interfaces - SFP module slots quantity - 4
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 36 W
Power consumption - 36 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power supply - Input voltage: 100 - 240 V AC, 50 - 60 Hz
Power supply - External
producer - Intellinet
Producer - Intellinet
producerCode - 561334
ProducerCode - 561334
ProductName - 48-Port Gigabit Ethernet Web-Managed Switch with 4 SFP Ports, 48 x 10/100/1000 Mbps RJ45 Ports + 4 x SFP, IEEE 802.3az Energy Efficient Ethernet, SNMP, QoS, VLAN, ACL, 19 Rackmount" (Euro 2-pin plug)
productName - Intellinet 48-Port Gigabit Ethernet Web-Managed Switch with 4 SFP Ports, 48 x 10/100/1000 Mbps RJ45 Ports + 4 x SFP, IEEE 802.3az Energy Efficient Ethernet, SNMP, QoS, VLAN, ACL, 19 Rackmount" (Euro 2-pin plug)
productSize - Normal
Protocols - Supported network protocols - IPv4, IPv6
QoS - Support for two types of QoS: port-based and DSCP
Security -
Security - IGMP snooping - Yes
Security - Security algorithms - SNMP
Security - Security algorithms - SNMP, SSH-2
Security - Security algorithms - SSH-2
ShortDescription - 48 portów Gigabit + 4 porty SFP
ShortSummaryDescription - Intellinet 48-Port Gigabit Ethernet Web-Managed Switch with 4 SFP Ports, 48 x 10/100/1000 Mbps RJ45 Ports + 4 x SFP, IEEE 802.3az Energy Efficient Ethernet, SNMP, QoS, VLAN, ACL, 19 Rackmount" (Euro 2-pin plug), Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex
sizeX - 380
sizeY - 560
sizeZ - 560
Stackability - No
Supported protocols and standards - IEEE 802.1d (Spanning Tree protocol) IEEE 802.1p (Traffic Prioritization) IEEE 802.1q (VLAN Tagging) IEEE 802.1s (Spanning Tree Protocol (MSTP) IEEE 802.3ad (Link Aggregation) IEEE 802.3 (10Base-T Ethernet) IEEE 802.3ab (Gigabit Ethernet Twisted Pair) IEEE 802.3ad (Link Aggregation Control LACP Protocol) IEEE 802.3az (Energy Efficient Ethernet EEE) IEEE 802.3u (100Base-TX Fast Ethernet) IEEE 802.3x (Flow control, full duplex) SNMPv1/v2 (Simple Network Management Protocol)
Support for Jumbo frames - Yes
Switch class - Managed
Throughput - 104 Gb/s
Title - Intellinet 48-Port Gigabit Ethernet Web-Managed Switch with 4 SFP Ports, 48 x 10/100/1000 Mbps RJ45 Ports + 4 x SFP, IEEE 802.3az Energy Efficient Ethernet, SNMP, QoS, VLAN, ACL, 19 Rackmount" (Euro 2-pin plug)
URL - https://intellinetnetwork.eu/catalogsearch/result/?q=561334
vendpn - 561334
VLAN - VLAN support based on tags or ports (tag-based, port-based)
WarrantyInfo - Three-Year Warranty
warrantyLength - 36
warrantyType - G
Weight - 4.2 kg
weight - 5500
Weight & dimensions - Depth - 335 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 4.2 kg
Weight & dimensions - Width - 440 mm
