Accessories included - 1x IB-DK2254AC 1x external power supply 1x power cable with EU plug 1x USB Type-C to Type-C/Type-A cable 1x manual
Brand - ICY BOX
BrandPartCode - 60802
Category - Laptop Docks & Port Replicators
Category_1 - Computers and Laptops
Category_2 - Laptop - Accessories
Color - Black
Compatible with -
Description - IB-DK2254AC
USB Type-C & Type-A DockingStation
with triple video output From a good DockingStation we expect connectivity, reliable performance, good design and advanced technology. With the IB-DK2254AC,
these expectations are fulfilled. Our DockingStation is extremely versatile and creates a full-fledged workstation at home or in the office. The
IB-DK2254AC supports both DisplayLink and DisplayPort Alt Mode. This allows you to connect three additional monitors and expand the
visible screen area. With a resolution of up to 3x 4K or 1x 5K, you can work even more effectively as annoying switching between programmes
is reduced. There are also six USB 3.0 Type-A ports for your peripherals and a 3.5 mm combo jack for the headset. Power Delivery with up to
100 W is supported via the host connection. So you can charge your notebook or MacBook while youre at it
dimension depth - 90 mm
dimension height - 235 mm
Dimensions - 0,085x0,200x0,030m
dimension weight - 1233 g
dimension width - 150 mm
Docking connector - No
ean - 4250078171386
EAN_code - 4250078171386
GTIN - 4250078171386
guarantee - 24
guarantee_type - normal
I/O ports - 1 x 3,5 mm minijack (Combo)
I/O ports - 1 x RJ-45 (LAN)
I/O ports - 1 x USB 3.0 Type C
I/O ports - 6 x USB 3.0 Type A
Logistics data - Harmonized System (HS) code - 84733020
LongDesc - Absolute flexibilityThe IB-DK2254AC DockingStation turns your notebook into a fully-fledged workstation. Simply connect the DockingStation to your notebook via USB Type-A or USB Type-C®. You have 6x USB 3.0 Type-A with up to 5 Gbit/s at your disposal, enabling you to connect hard drives and other devices.See more, work efficientlyThe ICY BOX® DockingStation supports both DisplayLink® and DisplayPort™ Alt Mode. This allows you to connect three additional monitors and expand the visible screen area. With a resolution of up to 3x 4K@60 Hz, you can work even more effectively because annoying switching between programmes is reduced.Always well connectedYou can establish a fast and secure network connection via the Gigabit Ethernet connection of the DockingStation. This means you are independent of WLAN reception. For undisturbed video conferencing, just connect your headset to a 3.5 mm combo jack. Of course, you can also simply listen to your favourite music.
LongProductName - 1x USB C, 6x USB 3.0 A, 3x HDMI, 3x DisplayPort, 85x230x150 mm
LongSummaryDescription - ICY BOX IB-DK2254AC. Connectivity technology: Wired, Host interface: USB 3.2 Gen 2 (3.1 Gen 2) Type-C. Ethernet LAN data rates: 10,100,1000 Mbit/s. Product colour: Black, HD type: 4K Ultra HD, Maximum digital resolution: 3840 x 2160 pixels. Power source type: AC, AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Other operating systems supported: ChromeOS
Manufacturer - Icy Box
Manufacturer_code - IB-DK2254AC
Name - ICY BOX IB-DK2254AC, docking station (black, USB-C, HDMI, DisplayPort)
name - ICY BOX IB-DK2254AC 11in1, 3xHDMI, PD 100W
Network - Ethernet LAN - Yes
Network - Ethernet LAN (RJ-45) ports - 1
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Other features -
Packaging content - AC adapter included - Yes
Packaging content - Cables included - AC, USB
Packaging content - Manual - Yes
Packaging data - Package depth - 360 mm
Packaging data - Package height - 185 mm
Packaging data - Package weight - 1.22 kg
Packaging data - Package width - 250 mm
Packaging data - Quantity per pack - 1 pc(s)
Performance - Card reader integrated - No
Performance - Country of origin - Thailand
Performance - HD type - 4K Ultra HD
Performance - Housing material - Plastic
Performance - LED indicators - Yes
Performance - Maximum digital resolution - 3840 x 2160 pixels
Performance - Product colour - Black
Performance - UASP support - Yes
Ports & interfaces - Combo headphone/mic port - Yes
Ports & interfaces - Connectivity technology - Wired
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - DisplayPorts quantity - 3
Ports & interfaces - HDMI ports quantity - 3
Ports & interfaces - Host interface - USB 3.2 Gen 2 (3.1 Gen 2) Type-C
Ports & interfaces - Microphone in - No
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 6
Ports & interfaces - USB Power Delivery - Yes
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Output current - 6.75 A
Power - Output voltage - 20 V
Power - Power source type - AC
Power - Power supply - 135 W
producer - IcyBox
ProductName - IB-DK2254AC
ShortSummaryDescription - ICY BOX IB-DK2254AC, Wired, USB 3.2 Gen 2 (3.1 Gen 2) Type-C, 10,100,1000 Mbit/s, Black, 4K Ultra HD, 3840 x 2160 pixels
Software - Mac operating systems supported - Yes
Software - Other operating systems supported - ChromeOS
Software - Windows operating systems supported - Yes
System Requirements - Windows/macOS/Chrome OS
Title - ICY BOX IB-DK2254AC Wired USB 3.2 Gen 2 (3.1 Gen 2) Type-C Black
URL - https://icybox.de/en/product.php?id=515
vendpn - IB-DK2254AC
WarrantyInfo -
Weight - 1.375 kg
Weight - 2,36
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 85 mm
Weight & dimensions - Weight - 287 g
Weight & dimensions - Width - 230 mm
