Accessories included - Multi-Port Travel Docking Station USB Type-C, 8 ports User manual
Code - DA-70866
Color - Silver
Compatible with - Universal docking station
Description - Multi-Port Travel Docking Station USB Type-C, 8 ports 4K, HDMI, VGA, 2x USB-C, 2x USB3.0, RJ45, microSD, SD/MMC, silver
The most important connectors are always available. Increase the number of notebook connectors by a further 8 connectors using the USB Type-C port
Thanks to the Digitus multi-port travel dock, you have all the important connectors always with you. The docking station expands the notebook with eight more ports. It has two video ports (HDMI and VGA). Supports the highest possible resolutions (HDMI): UHD with excellent image quality (4K2K / 30 Hz). The docking station also has two USB 3.0 ports, one of which has the function of charging mobile devices (BC 1.2). It also has a USB-C port (loading 3.0 + data transmission). The Gigabit Ethernet connection allows you to connect your notebook to the network using a cable. The whole is complemented by two card readers (MicroSD, SDHC, SDXC / MMC). Thanks to its compact dimensions, light weight and the ability to hide the connection cable, the multi-port travel station is the ideal device for travel.
Features:
Ultra HD support (30 Hz), 3840 x 2160p resolution (HDMI) 2 video connectors (HDMI, VGA) outgoing video signals with max. UHD resolution 4K / 30 Hz (HDMI) 2 USB 3.0 ports for data transmission at Super Speed, one with charging function (BC 1.2) for mobile devices (5 V / 1.5 A) Ultra HD support (30 Hz), 3840 x 2160p resolution (HDMI) USB Type-C port charging (PD) 3.0 (100 W, 20 V / 5 A max.) + Data transmission (5 Gbit / s max.) Gigabit Ethernet connection to connect the notebook to the network using a cable 2 card readers (MicroSD / SDHC, SDXC, MMC) Retractable USB Type-C connection cable (10 cm) The connection cable can be hidden in the housing Stylish aluminum housing Extremely compact dimensions and light weight ideal for travel
dimension depth - 25 mm
dimension height - 160 mm
Dimensions - 12.5 x 6.1 x 1.5 cm
dimension weight - 228 g
dimension width - 115 mm
EAN - 4016032450443
ean - 4016032450443
guarantee - 24
guarantee_type - external
I/O ports - 1 x D-Sub
I/O ports - 1 x HDMI Type A
I/O ports - 1 x RJ-45 (LAN)
I/O ports - 1 x USB 3.0 Type C
I/O ports - 2 x Card reader
I/O ports - 2 x USB 3.0 Type A
Link - https://de.assmann.shop/en/Computer-and-Office-Accessories/Computer-Accessories/USB-Components-and-Accessories/Docking-Stations-and-Docks/USB-Type-C-Multiport-Travel-Dock-8-Port.html
Name - Digitus | USB-C Multiport Travel Dock | DA-70866 | Docking station | Ethernet LAN (RJ-45) ports 1 | VGA (D-Sub) ports quantity 1 | USB 3.0 (3.1 Gen 1) ports quantity 2 | HDMI ports quantity 1 | Warranty 24 month(s)
name - Docking Station USB Type C
Other features -
Other features > Colour - Black
Other features > Dimensions (WxDxH) - 168x78x30 mm
Other information - The video display options depend on the graphics card of your notebook and the connected monitor. Certain graphics cards have limited MST support, while some monitors also limit the available resolution.
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 160.00 mm
Package features > Gross height (mm) - 25.00 mm
Package features > Gross width (mm) - 115.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 3757 pc(s)
Package features > Paper/Pasteboard - 640 g
Package features > Plastic (No PET) - 30.00 g
Package features > Tare weight (kg) - 0.03 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Ports & interfaces > Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > HDMI ports quantity - 1
Ports & interfaces > USB 3.0 (3.1 Gen 1) ports quantity - 2
Ports & interfaces > VGA (D-Sub) ports quantity - 1
producer - Digitus
Producer product family - USB-C Multiport Travel Dock
Producer product name - DA-70866
System Requirements - USB-C port supporting DisplayPort Alternate Mode (DP-Alt Modi) and USB Power Delivery (PD)
Technical details > Gross weight - 0.23 kg
Technical details > Net weight - 0.20 kg
Technical details > Other features - 2 x card readers (MicroSD / SDHC, SDXC, MMC)
Technical details > Producer - Digitus
Technical details > Type - Docking station
Technical details > Warranty - 24 month(s)
Technical details > Warranty - 24 year(s)
vendpn - DA-70866
Warranty - 24
Weight - 135 g
