APC Back-UPS BX2200MI-GR 2200VA, 1200W

Accessories included -
Active power - 1200 W
Alarm -

Alarm when on battery

Distinctive low battery alarm

Apparent power - 2200 VA
ARTIKEL1 - APC BACK-UPS 2200VA 230V AVR
ARTIKEL2 - SCHUKO SOCKETS
Backup time (100% load) - 1 min
Battery - Battery life (max) - 2 year(s)
Battery - Battery recharge time - 8 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Typical backup time at full load - 1 min
Battery - Typical backup time at half load - 8.5 min
BatteryType - Lead-acid
Brand - APC
BrandPartCode - BX2200MI-GR
Breite - 0.29
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category - Uninterruptible Power Supplies (UPSs)
Category 1 - Energie & USV
Category 2 - USV & Stromversorgung
Category_1 - Power
Category_2 - UPS
Certificates - Certification - CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Certificates - Compliance certificates - RoHS
Charging time - 6 h
Chassis type - Tower
Color - Black
ControlPanel -

LED status display with On Line

On Battery

Depth - 390 mm
Depth, mm - 390
Description - APC BACK-UPS 2200VA, 230V, AVR, SCHUKO SOCKETS
Description - Seria APC Back-UPS BX to ekonomiczne rozwiązanie do ochrony zasilania w domu i biurze domowym. Szeroka gama serii VA z funkcjami premium dodatkowo umożliwia wykorzystanie możliwości pojedynczego zasilacza UPS
Design - Cable length - 1.2 m
Design - Form factor - Compact
Design - International Protection (IP) code - IP20
Design - LED indicators - Yes
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 240 mm
dimension height - 490 mm
Dimensions - 190 x 140 x 390 mm
dimension weight - 9000 g
dimension width - 290 mm
ean - 731304410881
EAN - 0731304410881
EANCode - 0731304410881
Eans - 0731304410881
EAN_code - 0731304410881
Environment requirements - Środowisko pracy: 0 - 40 °C Wilgotność względna podczas pracy: 0 - 95% Wysokość robocza: 0-3000 metrów Temperatura przechowywania: 15 - 40 °C Wilgotność względna przechowywania: 0-95%
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Low battery alarm
Features - Automatic Voltage Regulation (AVR) - Yes
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 300 V
Features - Input operation voltage (min) - 140 V
Features - Input power factor - 0.54
Features - Noise level - 40 dB
Features - Output frequency - 50/60 Hz
Features - Output frequency regulation - 0.5 Hz
Features - Output operation voltage (max) - 230 V
Features - Output operation voltage (min) - 230 V
Features - Output power - 1200 W
Features - Output power capacity - 2.2 kVA
Features - Output voltage regulation - 10%
Features - Response time - 6 ms
Features - Surge energy rating - 273 J
Features - Surge protection - Yes
Features - UPS topology - Line-Interactive
Features - Waveform - Sine
FormFactor - Tower
Form factor - Tower
Gewicht - 13.72
GrossWeight - 8.000 kg
Gross Weight Kg - 13,3
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 0731304410881
GTIN - 731304410881
guarantee - 24
guarantee_type - external
Height - 190 mm
Height - 290.000000
Height, mm - 190
HERSTELLER - APC
Hoehe - 0.24
HSTNUMMER - BX2200MI-GR
I/O connectors - 1 x USB (Type B)
I/O connectors - 2 x RJ-45 (iLO Remote Management Network)
InputConnections - -
InputFrequency - 50/60 Hz +/- 5 Hz Auto-sensing
Input power ports - Wtyczka sieciowa
InputVoltage - 140 - 300V
InterfacePorts - -
Laenge - 0.5
Length - 495.000000
Logistics data - Harmonized System (HS) code - 85078000
LongDesc -
LongDesc - This APC Back-UPS offers power and surge protection for wireless networks, computers, gaming consoles and other electronics in your home or business. The 2200VA tower UPS has 4 total outlets, all of which provide battery back up and surge protection. It has a surge energy rating of 273 Joules. It features Automatic Voltage Regulation to correct voltage dips and surges to proper levels. This UPS has a 2-year warranty and CE product certification.
LongProductName - Back-UPS, 2200VA, Tower, 230V, 4x CEE 7/7 Schuko outlets, AVR
LongSummaryDescription - APC Back-UPS, 2200VA, Tower, 230V, 4x CEE 7/7 Schuko outlets, AVR. UPS topology: Line-Interactive, Output power capacity: 2.2 kVA, Output power: 1200 W. AC outlet types: Type F, Power plug: Type F, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 1 min, Typical backup time at half load: 8.5 min. Form factor: Compact, Product colour: Black, Cable length: 1.2 m. Compliance certificates: RoHS, Certification: CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Manufacturer - APC
Manufacturer Code - BX2200MI-GR
Manufacturer Name - APC by Schneider Electric
ManufacturerPartNumber - BX2200MI-GR
Manufacturer_code - BX2200MI-GR
MANUFDATASHEET - https://www.apc.com/shop/us/en/products/APC-Back-UPS-2200VA-230V-AVR-4-Schuko-outlets/P-BX2200MI-GR
MPN - BX2200MI-GR
Name - APC Back-UPS BX MI 2200VA / 230V Schuko
Name - APC Back-UPS Tower BX2200MI-GR 1200W 2200VA 4 Schuko Ausgänge
Name - APC Back BX2200MI-GR
name - BX2200MI-GR Back-UPS 2200VA,230V,AVR,4 Schuko
No. of batteries - 1
Nominal input voltage, V - 230
Nominal output voltage, V - 230
Number of phases input - 1 (230V)
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -15 - 40 °C
Other features -
OutputConnections - -
OutputFrequency - 50/60 Hz +/- 1 Hz Sync to mains
Output power capacity (VA) - 2200
Output power ports - 4 x C/F type (Schuko)
OutputVoltage - -
PackageContents - -
Packaging content - Cables included - Input power cable
Packaging content - Manual - Yes
Packaging data - Package depth - 495 mm
Packaging data - Package height - 297 mm
Packaging data - Package weight - 13.3 kg
Packaging data - Package width - 235 mm
PeriodofWarranty - 2 Y
Ports & interfaces - AC outlets quantity - 4 AC outlet(s)
Ports & interfaces - AC outlet types - Type F
Ports & interfaces - Power plug - Type F
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
Ports & interfaces - USB port type - USB Type-B
PowerVAW - 2200 VA
PowerW - 1200 W
ProdDesc - APC Back-UPS 2200VA, 230V, AVR, Schuko Sockets
producer - APC
Producer - APC
ProducerCode - BX2200MI-GR
ProductName - Back-UPS, 2200VA, Tower, 230V, 4x CEE 7/7 Schuko outlets, AVR
ProductPicture - http://www.tdbaltic.ee/images/ds4/BX1200MI-01.jpg
ProductPicture2 - http://www.tdbaltic.ee/images/ds4/BX2200MI-02.jpg
ProductPicture3 -
ProductPicture4 -
RechargeTime - 8 h
RJ45 - -
Runtime - 9.5/2.25
ShortDescription -
Short description - APC Back-UPS BX 2200 VA BX2200MI-GR
ShortSummaryDescription - APC Back-UPS, 2200VA, Tower, 230V, 4x CEE 7/7 Schuko outlets, AVR, Line-Interactive, 2.2 kVA, 1200 W, Sine, 140 V, 300 V
SmartSlot - -
Software -
Special functions - AVR
Stck_Kart - 1
Stck_Pal - 18
Storno - N
Title - APC Back-UPS, 2200VA, Tower, 230V, 4x CEE 7/7 Schuko outlets, AVR
Topology - Line interactive
UPS Architecture - line-interactive
UPS devices and accessories - Yes
URL - https://www.apc.com/
USB - -
vendpn - BX2200MI-GR
Warranty - 2 years
WarrantyInfo - 2 years
WaveformType - Stepped approximation to a sinewave
Weight - 12.3 kg
Weight - 12.300 kg
Weight - 13,60
Weight - 13.710000
Weight - 14.18
Weight & dimensions - Depth - 390 mm
Weight & dimensions - Height - 190 mm
Weight & dimensions - Weight - 12.3 kg
Weight & dimensions - Width - 140 mm
Weight, kg - 12.3
Width - 140 mm
Width - 235.000000
Width, mm - 140
