Incase 4-Port USB DVI/Audio KVMP Switch Aten 4-Port USB DVI/Audio KVMP™ Switc

Brand - ATEN
BrandPartCode - CS1764A-AT-G
Category - KVM Switches
Code - CS1764A-AT-G
Design - Hot keys - Yes
Design - Housing material - Metal
Design - LED indicators - Yes
Design - Product colour - Black
Design - Push button - Yes
Display - Built-in display - No
EAN - 4710423776449
GTIN - 4710423776449
Logistics data - Harmonized System (HS) code - 85176200
Logistics data - Master (outer) case gross weight - 12.7 kg
Logistics data - Master (outer) case height - 232 mm
Logistics data - Master (outer) case length - 512 mm
Logistics data - Master (outer) case net weight - 10.5 kg
Logistics data - Master (outer) case width - 342 mm
Logistics data - Products per master (outer) case - 5 pc(s)
LongDesc - The CubiQ™ CS1764A USB 2.0 DVI KVMP™ Switch charts a revolutionary new direction in KVM (Keyboard, Video, Mouse) switch functionality by combining a 4 port KVM switch with a 2 port USB 2.0 hub at the same time as it provides an interface for a digital monitor (DVI).1 x CS1764A USB 2.0 DVI KVMP™ Switch4 x 2L-7D02U USB DVI-D Single Link KVM Cables (1.8m) 1 x 0AD8-1605-24M1 Power Adapter1 x User Instructions
LongProductName - 4-Port USB DVI KVM Switch with Audio & USB 2.0 Hub (KVM Cables included)
LongSummaryDescription - ATEN 4-Port USB DVI KVM Switch with Audio & USB 2.0 Hub (KVM Cables included). Keyboard port type: USB, Mouse port type: USB, Video port type: DVI-I. HD type: WUXGA, Maximum resolution: 1920 x 1200 pixels, Video bandwidth: 60 Hz. Product colour: Black, Housing material: Metal. Power source: DC, Input voltage: 5.3 V, Power consumption (typical): 4.8 W. Width: 270 mm, Depth: 88 mm, Height: 55.5 mm
Name - Aten 4-Port USB DVI/Audio KVMP Switch | Aten | 4-Port USB DVI/Audio KVMP™ Switc
Operational conditions - Operating relative humidity (H-H) - 0 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 80%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Operational conditions > Temperature range (T-T) - 0 - 50°C °C
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 27.00 mm
Package features > Gross height (mm) - 5.55 mm
Package features > Gross weight - 1.25 kg
Package features > Gross width (mm) - 8.80 mm
Package features > Packing quantity - 1 pc(s)
Package features > Palette Qty - 800 pc(s)
Package features > Paper/Pasteboard - 300 g
Package features > Plastic (No PET) - 10 g
Package features > Tare weight (kg) - 0.31 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Manual - Yes
Packaging content - Quick installation guide - Yes
Packaging data - Package depth - 325 mm
Packaging data - Package height - 210 mm
Packaging data - Package weight - 2.41 kg
Packaging data - Package width - 98 mm
Performance - DDC2B support - Yes
Performance - HD type - WUXGA
Performance - Maximum resolution - 1920 x 1200 pixels
Performance - Scan interval - 1,5,99 s
Performance - Video bandwidth - 60 Hz
Ports & interfaces - Audio connections - Yes
Ports & interfaces - Console ports - 3.5mm headphone, 3.5mm mic, DVI-I, USB A
Ports & interfaces - Console USB ports quantity - 4
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - DVI-I ports quantity - 4
Ports & interfaces - Headphone outputs - 6
Ports & interfaces - Keyboard port type - USB
Ports & interfaces - Mouse port type - USB
Ports & interfaces - Number of computers controlled - 4
Ports & interfaces - Number of microphone inputs - 6
Ports & interfaces - USB 2.0 Type-B ports quantity - 4
Ports & interfaces - USB connector type - USB Type-A, USB Type-B
Ports & interfaces - USB hub - Yes
Ports & interfaces - Video port type - DVI-I
Power - Input voltage - 5.3 V
Power - Power consumption (typical) - 4.8 W
Power - Power source - DC
Producer product name - 4-Port USB DVI/Audio KVMP™ Switc
ProductName - 4-Port USB DVI KVM Switch with Audio & USB 2.0 Hub (KVM Cables included)
ShortSummaryDescription - ATEN 4-Port USB DVI KVM Switch with Audio & USB 2.0 Hub (KVM Cables included), 1920 x 1200 pixels, WUXGA, 4.8 W, Black
Technical details > Net weight - 0.94 kg
Technical details > Other features - Superior video quality – 1920 x 1200. Computer selection via front panel pushbuttons, hotkeys, and mouse. DVI digital and analog monitor support – fully compliant with the DVI specifications. Multiplatform support – Windows, Linux, Mac, and Sun. "Console Ports - 2 x USB Type A Female (White; front panel). 1 x DVI-I Female (White). 2 x Mini Stereo Jack Female (Green; 1 x front panel; 1 x rear panel). 2 x Mini Stereo Jack Female (Pink; 1 x front panel; 1 x rear panel)." "KVM Ports - 4 x USB Type B Female (White), 4 x DVI-I Female (White), 4 x Mini Stereo Jack Female (Green), 4 x Mini Stereo Jack Female (Pink), " Power- 1 x DC Jack USB Hub.
Technical details > Producer - Aten
Title - ATEN 4-Port USB DVI KVM Switch with Audio & USB 2.0 Hub (KVM Cables included)
URL - https://www.aten.com/eu/en/products/kvm/desktop-kvm-switches/cs1764a/
Warranty - 24
Warranty - 24 month(s)
WarrantyInfo -
Weight & dimensions - Depth - 88 mm
Weight & dimensions - Height - 55.5 mm
Weight & dimensions - Weight - 2.1 kg
Weight & dimensions - Width - 270 mm
