Synology HAT5300 4TB SATA HDD

Additional part number -
Buffer - 256 MB
Category_1 - Hard Drives and Pendrives
Category_2 - Internal Hard Drives - SATA - 3.5 inch
Code - HAT5300-4T
Compatible with - Seria SA: SA3600, SA3400 Seria 22: RS422+, DS3622xs+, DS2422+, DS1522+, DVA1622 Seria 21: RS4021xs+, RS3621xs+, RS3621RPxs, RS2821RP+, RS2421RP+, RS2421+, RS1221RP+, RS1221+, DS1821+, DS1621xs+, DS1621+, DVA3221 Seria 20: RS820RP+, RS820+, DS1520+, DS920+, DS720+, DS420+, DS220+ Seria 19: RS1619xs+, DS2419+II, DS2419+, DS1819+, DVA3219 Seria 18: RS3618xs, RS2818RP+, RS2418RP+, RS2418+, DS3018xs, DS1618+ Seria 17: RS18017xs+, RS4017xs+, RS3617xs+, RS3617RPxs, DS3617xsII, DS3617xs
Depth - 147 mm
Description - HAT5300 SATA 3.5 Hard Disk Drive (HDD) Designed for demanding workloads and high-capacity arrays The Synology HAT5300 drive is designed to support demanding data-intensive workloads. Optimized for Synology storage solutions, the design delivers high sequential throughput, maximizing the number of clients the system can support simultaneously. The HAT5300 series drives are designed for maximum reliability, passing over 400,000 hours of verification and are backed by Synology's 5-year limited warranty. Key Features Enterprise-class reliability and durability: For demanding 24/7 environments with an estimated mean time to failure (MTTF) of up to 2.5 million hours and data loads of up to 550 TB per year. Persistent write cache technology: Minimises the risk of data corruption in the event of a severe power loss. Better together: Firmware and DiskStation Manager (DSM) optimizations improve sequential reads from multiple clients and boost performance by 23%1. All updates in one place: Download automatic firmware updates via DSM updates, reducing the need for additional maintenance sessions. For Synology, from Synology: Rigorous validation and up to 400,000 hours of testing ensure maximum reliability for Synology systems.
dimensionalWeight - 201
dimension depth - 40 mm
dimension height - 180 mm
dimension weight - 705 g
dimension width - 130 mm
Disk type - HDD
Drive type - Internal
EAN - 4711174724635
ean - 4711174724635
EAN_code - 4711174724635
Features - 24/7 operation - Yes
Features - Component for - Server/workstation
Features - HDD capacity - 4 TB
Features - HDD size - 3.5"
Features - HDD speed - 7200 RPM
Features - HDD sustained transfer rate - 243 MiB/s
Features - Interface - Serial ATA III
Features - Mean time to failure (MTTF) - 2000000 h
Features - Storage drive buffer size - 256 MB
Features - Type - HDD
Features - Workload rate limit - 550 TB/year
Form factor (width) - 3,5'' (LFF)
Gross Weight Kg - 1
guarantee - 60
guarantee_type - normal
Hard drive > Hard drive interface - SATA
Hard drive > Hard drive size - 3.5 "
Hard drive > Hard drive speed - 7200 RPM
HDD capacity - 4 TB
HDD interface - SATA III - 6 Gb/s
Height - 26.1 mm
Important -
Link - https://www.synology.com/en-global/products/hard_drives/HAT5300#specs
Logistics data - Harmonized System (HS) code - 84717050
Manufacturer - Synology
Manufacturer Code - HAT5300-4T
Manufacturer Name - Synology
Manufacturer_code - HAT5300-4T
Mean time between failures (MTBF) - 2000000 h
Model - HAT5300-4T
name - HDD drive SATA 4TB HAT5300-4T 3,5 inches SATA 6Gb/s 512e 7,2k
Name - Synology HAT5300-4T, Hard Drive (SATA 6 Gb/s, 3.5, 24/7)
Name - Synology | Hard Drive | HAT5300-4T | 7200 RPM | 4000 GB
Operational conditions - Non-operating altitude - -305 - 12192 m
Operational conditions - Non-operating shock - 300 G
Operational conditions - Non-operating vibration - 3 G
Operational conditions - Operating altitude - -305 - 3048 m
Operational conditions - Operating relative humidity (H-H) - 5 - 90%
Operational conditions - Operating shock - 70 G
Operational conditions - Operating temperature (T-T) - 5 - 60 °C
Operational conditions - Operating vibration - 0.75 G
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - Certifications: CE, RCM, BSMI, KC, EAC, UL, TUV, ICES, UKCA, RoHS Warranty: 5 years
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 135 mm
Package features > Gross depth master carton - 500 mm
Package features > Gross height (mm) - 180 mm
Package features > Gross height master carton - 240 mm
Package features > Gross width (mm) - 40 mm
Package features > Gross width master carton - 315 mm
Package features > Net weight master carton - 14.12 kg
Package features > Packing quantity - 20 pc(s)
Package features > Palette Qty - 900 pc(s)
Package features > Paper/Pasteboard - 100.00 g
Package features > Plastic (No PET) - 40.00 g
Package features > Tare weight (kg) - 0.10 kg
Package features > Tare weight master carton - 0.378 kg
Package features > Volume (m3) - 0.000972 m³
Package features > WEEE tax - No
PDF - https://www.blobs.lt/products/6/1/6/4/6/3/b86080aec71ad123df6f7d6c6bbd6551/original.pdf
Performance > Capacity - 4000 GB
Power - Operating voltage - 5 / 12 V
Power - Power consumption (idle) - 4.07 W
Power - Power consumption (read) - 7.76 W
Power - Power consumption (write) - 7.76 W
Power consumption - 4.07 W
producer - Synology
producerCode - HAT5300-4T
Producer product family - Hard Drive
Producer product name - HAT5300-4T
productName - Synology HAT5300-4T internal hard drive 3.5" 4 TB Serial ATA III
productSize - Normal
Rotational Speed - 7200 RPM
Sector size - 512n
Short description - Synology NAS HD3.5" SATA 4TB HAT5300-4T / 7,2k
sizeX - 180
sizeY - 40
sizeZ - 140
Technical details - Compliance certificates - CE
Technical details - Compliance certificates - RoHS
Technical details - Sustainability certificates - CE
Technical details - Sustainability certificates - RoHS
Technical details > Gross weight - 0.706 kg
Technical details > Net weight - 0.606 kg
Technical details > Producer - Synology
vendpn - HAT5300-4T
Warranty - 60
Warranty - 60 month(s)
warrantyLength - 60
warrantyType - F
Weight - 0,71
Weight - 693 g
weight - 700
Weight & dimensions - Depth - 147 mm
Weight & dimensions - Height - 26.1 mm
Weight & dimensions - Weight - 693 g
Weight & dimensions - Width - 101.8 mm
Width - 101.85 mm
