Lindy Active USB-A 3.0 Extension Cable Pro, 15m

Brand - Lindy
BrandPartCode - 43229
Cable length - 15m
Category - USB Cables
Category Code - UCB
Category_1 - Cables
Category_2 - Network Cables
Colour - Black
Connectors - USB Type A Male/USB Type A Female
Description - 15m USB 3.0 Active Extension Pro Extend USB 3.0 connections up to 40m The Lindy USB Active Extension Cable Pro is a high performance active cable that allows access to USB 3.0 SuperSpeed peripherals over long distances. With support for data transfer speeds of up to 5Gbps this extension cable is perfect for transferring large data volumes quickly and reliably. This 15m extension cable can be used standalone or as part of the Lindy USB 3.0 Active Extension System Pro. This system is a modular solution that can combine multiple USB Active Extension Pro cables and a USB 3.0 Active Extension Pro hub to distribute USB signals to up to 4 devices at about 40m (depending on the cable configurations used).
EAN_code - 4002888432290
Features - AWG wire size - 24/24/20
Features - Cable jacket material - Polyvinyl chloride (PVC)
Features - Cable type - Round cable
Features - Certification - CE, UKCA, FCC, RoHS, REACH, California Proposition 65
Features - Conductor material - Tinned copper
Features - Connector 1 - USB A
Features - Connector 1 form factor - Straight
Features - Connector 1 gender - Male
Features - Connector 2 - USB A
Features - Connector 2 form factor - Straight
Features - Connector 2 gender - Female
Features - Connector contacts plating - Gold
Features - Connector housing material - Plastic
Features - Connector material - Nickel
Features - Contact material - Brass
Features - Maximum data transfer rate - 5 Gbit/s
Features - Maximum data transfer rate - 5000 Mbit/s
Features - Nominal attenuation - 0.064MHz - 0.08dB
.256MHz - 0.11dB
0.512MHz - 0.13dB
0.772MHz - 0.15dB
1.0MHz - 0.20dB
4MHz - 0.39dB
8MHz - 0.57dB
12MHz - 0.67dB
24MHz - 0.95dB
48MHz - 1.35dB
96MHz - 1.90dB
200MHz - 3.20dB
400MHz - 5.80dB
Features - Product colour - Black
Features - Transmission medium - Twisted pair
Features - USB version - USB 3.2 Gen 1 (3.1 Gen 1)
Full Description Line - Connectors USB Type A Male/USB Type A Female|Colour Black
GTIN - 4002888432290
Logistics data - Harmonized System (HS) code - 84733080
LongDesc - The Lindy 15m USB 3.0 Active Extension Cable Pro is a high-performance cable that allows a computer to connect to USB 3.0 SuperSpeed peripherals over long distances. It supports data transfer speeds of up to 5Gbps, making it ideal for quickly and reliably transferring large amounts of data.The cable incorporates proven active technology and locking connectors to ensure reliable signal integrity, even in demanding environments.This 15m extension cable can be used on its own or as part of the Lindy USB 3.0 Active Extension System Pro. This system is a modular solution that combines multiple USB Active Extension Pro cables and a USB 3.0 Active Extension Pro hub. It enables the distribution of USB signals to up to 4 devices at distances of up to 40m (depending on the cable configurations used).Using this cable as part of the USB 3.0 Active Extension System ProIf you would like to use this cable as part of combined Lindy USB 3.0 Active Extension System Pro installation, please note the requirements below.The first unit connected to your computer must always be the USB 3.0 Active Extension Pro 8m (No. 43158) or 15m (No. 43229). Once the first cable is connected, you can cascade additional Extension System Pro cables to extend the distance up to a maximum of 40m.The final part of the extension can be any cable or hub from the Extension System Pro range.If you need to extend multiple devices or connect a USB device with high power requirements, you should use the 10m Hub Pro unit (No. 43159) with its power supply as the final part of the extension.Information about USB 3.0, 3.1 and 3.2USB 3.0, USB 3.1 and USB 3.2 PCs, cables and devices are all compatible with each other, when using either a USB Type A or USB Type C host interface.USB 3.0, USB 3.1 Gen 1 and USB 3.2 Gen 1 all support data transfer rates up to 5 Gbps. USB 3.1 Gen 2 and USB 3.2 Gen 2 both support data transfer rates up to 10 Gbps.
LongProductName - 15m USB 3.0 Active Extension Pro
LongSummaryDescription - Lindy 15m USB 3.0 Active Extension Pro. Cable length: 15 m. Connector 1: USB A, Connector 2: USB A, USB version: USB 3.2 Gen 1 (3.1 Gen 1), Maximum data transfer rate: 5 Gbit/s, Connector contacts plating: Gold, Product colour: Black
Manufacturer - Lindy
Manufacturer_code - 43229
Model - 43229
Name - Lindy active extension cable USB 3.0 PRO 15m - 43229
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Packaging content - Quantity per pack - 1 pc(s)
Packaging data - Package depth - 180 mm
Packaging data - Package height - 10 mm
Packaging data - Package type - Box
Packaging data - Package weight - 1.35 kg
Packaging data - Package width - 280 mm
Power - Power note - 2.5/0.7mm DC Connector
ProductName - 15m USB 3.0 Active Extension Pro
Product Type - Cable
Shipping Box Depth Shipping/Package Box Dimensions - 33 cm
Shipping Box Height Shipping/Package Box Dimensions - 11.5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 1.4 kg
Shipping Box Width Shipping/Package Box Dimensions - 20 cm
ShortSummaryDescription - Lindy 15m USB 3.0 Active Extension Pro, 15 m, USB A, USB A, USB 3.2 Gen 1 (3.1 Gen 1), 5 Gbit/s, Black
Title - Lindy 15m USB 3.0 Active Extension Pro
Unit Box Height - 0.115
Unit Box Length - 0.33
Unit Box Width - 0.2
Unit Brutto Volume - 0.00759 cubm
Unit Gross Weight - 1.4 kg
Unit Net Weight - 1 kg
URL - https://www.lindy.co.uk/usb-c4/15m-usb-3-0-active-extension-pro-p10396
USB/Lightning cable type - USB to USB
Vendor Homepage - www.lindy-international.com/15m-USB-3-0-Active-Extension-Pro-.htm?websale8=ld0101.ld021102&pi=43229&ci=50
Warranty - 24 months
WarrantyInfo -
Weight - 1,40
Weight & dimensions - Bend radius (min) - 3.6 cm
Weight & dimensions - Cable diameter - 7 mm
Weight & dimensions - Cable length - 15 m
Weight & dimensions - Connector 1 dimensions (WxDxH) - 15 x 49 x 8 mm
Weight & dimensions - Connector 2 dimensions (WxDxH) - 20 x 80 x 13 mm
Weight & dimensions - Weight - 1 kg
