Cable length - 305 m
Category - CAT 5e
Color - Gray
Connectors #1 - None
Connectors #2 - None
Description - U/UTP installation cable (unshielded twisted-pair, 4-pair cable) is designed for horizontal and vertical internal installations in ICT networks.
- The outer shell of the cable is made of polyvinyl chloride (PVC);
- Cables meet the requirements of category 5e;
- Non-gelled cable made of 8 insulated conductors twisted into 4 pairs;
- The diameter of the cable is 5 ± 0.3 mm;
- The diameter of the conductor is 0.511 ± 0.005mm;
- The cable enables the use of PoE (Power over Ethernet) technology;
- The cable meets the following standards:
ISO / IEC 11801;
EN 50173-1;
IEC 61156-6;
EN 50288-2-2;
ANSI / TIA / EIA 568-C.2
dimensionalWeight - 5797
dimension depth - 360 mm
dimension height - 355 mm
dimension weight - 8295 g
dimension width - 235 mm
ean - 8719605002082
guarantee - 24
guarantee_type - external
name - Cable Tele-informatics, installation, U / UTP cat.5e 4x2xAWG24 / 1, wire, copper, PVC, 305m, gray
Other features - - Type AWG (avg. Wire): AWG 24
- Cable coating type (PVC / LS0H): PVC (Polyvinyl Chloride)
producer - Belden
producerCode - BL-1583E.00U305
productName - Belden UTPcab - 100MHz, 4P wire networking cable Grey 305 m
productSize - Normal
sizeX - 355
sizeY - 230
sizeZ - 355
Twisted-pair cable - U/UTP
Type - Cable
Usage - LAN
vendpn - BL-1583E.00U305
warrantyLength - 24
warrantyType - G
weight - 7620
